1) Support to detect optical signals without disrupting traffic; Based on non-destructive technology;
2) Indicate the signal direction in fiber;
3) Detect a variety of optical tones, 270Hz, 1kHz and 2kHz;
4) Suitable for 0.25, 0.9, 2.0, 3.0mm fiber, and no need to replace the clamp block, more convenient than others;
5) Build in visible fault locator 1mW or 10mW optional
6) Battery low indication;
7 Powered by 2 units of 1.5V AA alkaline batteries;
Main Characteristic
|
T-FI450
|
T-FI450V01 |
T-FI450V10 |
Wavelength Range |
800 to 1700nm (SM) |
||
Recognizable signal type* |
CW, 2kHz, 1kHz, 270Hz ±10% |
||
Detector Type |
InGaAs 2pcs |
||
Fiber Type |
0.9, 0.25, 2.0, 3.0 mm fiber |
||
Sensitivity |
+10 ~ -50dBm |
||
Accuracy * |
+10dB to -30 dBm (Continuous Wave) |
||
+10dB to -25 dBm (Modulated Signal) | |||
LED Indicator |
Signal direction; signal frequency (2kHz/1kHz/270Hz); low battery |
||
Visual Fault Locator |
No |
1mW |
10mW |
Storage Temperature |
-20 -- +60 °C, < 90%RH |
||
Operating Temperature |
-10 -- +50 °C, < 90%RH |
||
Power Supply |
AA * 2 |
||
Size |
230mm * 45mm * 45mm |
||
Weight |
About 200g |
||
* at 20±3°C, indoor, 1550nm wavelength, 0.9mm fiber, with white coat, 270Hz, error < 5%,
* 0.25, 2.0, 3.0mm fiber, the performance at continuous wave will be lower
* 1KHz, 2KHz, the performance at modulated signal will be lower
* at 1310nm wavelength, the performance will be lower
Accessories
Standard |
User’s manual |
1 |
Calibration certification |
1 |
|
Carrying bag |
1 |
