Wenzhou Yika 33KV Lightning Arrester Polymeric Power Distribution Units

Wenzhou Yika 33KV Lightning Arrester Polymeric Power Distribution Units photo-1
US$ 30 - 40 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YIKA
Model Number:
HY5W-33, HY10W-33
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name YIKA
Model Number HY5W-33, HY10W-33



  33KV Lightning Arrester Polymeric Power Distribution Units



Wenzhou Yika 33KV Lightning Arrester Polymeric Power Distribution UnitsWenzhou Yika 33KV Lightning Arrester Polymeric Power Distribution Units                                                             Wenzhou Yika 33KV Lightning Arrester Polymeric Power Distribution UnitsWenzhou Yika 33KV Lightning Arrester Polymeric Power Distribution Units







Wenzhou Yika 33KV Lightning Arrester Polymeric Power Distribution Units





Specifications

Normal operating conditions for Lightning Arrester :



1. The ambient air temperature is no higher than +40°C, no lower than -40 °C .

2. The altitude above sea level does not exceed 1000m. ( the plateau area should be indicated when order.)

3. AC system frequency is 50Hz or 60Hz.

4. Power frequency voltage brought to bear on arrester for a long time does not exceed the continuous operation voltage of the arrester.

5. Maximum wind speed does not exceed 35m/s.

6. Te earthquake intensity does not exceed 7 degrees.

7. The pollution area should be indicated.





Gapless Arrester Electrical Parameter

Type

Rated Voltage

MCOV

Max.Residual Viltage

2ms square wave impulse withstand current

High current impulse withstand 4/10μs

Steep current impuise1/4μS

Switching current lmpulse30/60μs

Nominal current lmpulse 8/20μs

kV

kV

kV

kV

kV

A

kV

HY5W-33

33

26.8

104.0

84.7

99

100

65

HY10W-33

33

26.8

104.0

84.7

99

250

100







Wenzhou Yika 33KV Lightning Arrester Polymeric Power Distribution Units



Packaging

Wenzhou Yika 33KV Lightning Arrester Polymeric Power Distribution Units

Wenzhou Yika 33KV Lightning Arrester Polymeric Power Distribution Units
