IP65 Dynamic Metal Keyboard With Touchpad Numeric Keypad for Kiosk

IP65 Dynamic Metal Keyboard With Touchpad Numeric Keypad for Kiosk thumbnail-1
IP65 Dynamic Metal Keyboard With Touchpad Numeric Keypad for Kiosk thumbnail-2
IP65 Dynamic Metal Keyboard With Touchpad Numeric Keypad for Kiosk photo-1
IP65 Dynamic Metal Keyboard With Touchpad Numeric Keypad for Kiosk photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Desktop
Type:
Wired
Contact Supplier Request Quote Chat Now
Key Technology (China) Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shen Zhen and HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Application Desktop
Type Wired
Style Standard, Other, Standard, 97 keys
Interface Type PS/2, USB
Brand Name IKB-MKB
Model Number K-TEK-A420TP-KP-FN
Place of Origin Guangdong, China

MODEL NO.: K-TEK-A420TP-KP-FN



DESCRIPTION:99 Keys Compact Format IP65 dynamic Vandal Proof Stainless steel industrial keyboard with sealed & ruggedized touchpad with scroll function (optional) for fast and accurate cursor position,industrial PCB with carbon-on-gold key switch technology with long stroke (2.0mm) with extremely good tactile feeling for fast and accurate data input without any noise, numeric keypad (optional PINPAD with Encryption Electronics Controller supporting DES/TDES),

function keys F1, F2..F10, F11, F12 are on the top line for easy operation, with top panel mounting solution.



DIMENSIONS:    420.0mm x 145.0mm x 20.0mm (L x W x H)



APPLICATION This Keyboard is mainly targeted for use for unsupervised or semi-supervised positions of varied access applications, internet terminals and information kiosks at universities, shopping malls, hotels, banks, airports, railway-stations and other public areas, ticket vending machines, gas stations, cash machines (ATMs/CDM), Internet public phones etcIP65 dynamic metal keyboard with touchpad numeric keypad for kioskIP65 dynamic metal keyboard with touchpad numeric keypad for kiosk



MAIN FEATURE

· Imposing stainless steel design, specially designed keyboards meet the highest demands with regard to design, functionality, longevity and high protection level.

· Stainless steel fascia and key-tops guard willful destruction, vandal-proof, against corrosion, weather-proof especially under extreme climatic conditions, water proof/dirt proof, operation under hostile environments.

· Waterproof execution according to IP65 protection from top panel.

· An excellent tactile feel with full-long travel switches and allow users to achieve fast and accurate data input without any noise. With firm tactile perception for comfortable operation

· Internet friendly key layout, key-tops are laser-etched in legends and characters for easy readability, long life to prevent lettering rub-off.

· Metal keys are protected against twisting and levering which can not be dislodged from front, or defaced removing key covers.

· Ease of customizing with multiple languages, to accommodate foreign or custom variants.

· Complete electronic modules including controller in close consultation with our customers are available.

· PS/2, USB connection plug-and-play with PC via PC existing OS driver, no needing of install separate driver.

· The numeric keypad between keyboard and trackball is available with encryption module supporting DES/TDES for bank usage of CDM/ATM.



ELECTRICAL DATA

· Supply Voltage: +5V DC +/-5%

· Current Rating: appr. 30mA

· EMC Standard:  It is compliance with the council IEC 61000-4-2:2008;

· IEC 61000-4-3:2006+AI:2007+A2:2010;IEC 61000-4-4:2004

· EMI: EN 55022: 2010

· EMS: EN 55024:2010

· Lifespan > 5 years

· Switch Contact Material: Carbon-on-Gold key switch technology PCB.

· Interface: PS2, USB available, RS232 for EPP

· If needed, numeric keypad is available to be with encryption electronics controller supporting DES/Triple DES.

· OS: All windows, Linux, Unix, Mac OSX

ENVIRONMENTAL ADAPTABILITY

· Operating temperature:-20oC to +60oC

· Storage temperature: -30oC to +70oC

· Operating RH: 30-90%

· Atmospheric pressure: 60-106Kpa.

· Saline mist: 96 hours, IEC 60512-6

· Damp heat test at + 40oC: 21 days, IEC 60512-6

· Dry heat test at + 85oC: 10 days, IEC 60512-6

RELIABILITY

· RoHS Compliant, CE and FCC, ESD

· Protection Level: IP65(front panel)

· Vandal resistant IK09

· Key Lifespan >10 million actuations

· MTBF >50000H

· MTTR <30min
