Vandal Proof Terminal Keyboard With Touch Pad
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Key-Tek
Model Number:
K-TEK-B392TP
Payment & Shipping
Payment Methods:
Port of Shipment:
Shen zhen and HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Compact Format Short ATM Keyboard Rear Mounting With Digital KeyboardNegotiableMOQ: 1 Set -
US Standard Layout Metal Keyboard With Excellent Tactile FeelingNegotiableMOQ: 1 Set
-
Stainless Steel Keyboard With Short Stroke, Rear MountingNegotiableMOQ: 1 Set
-
Compact Format Vandal Proof IP65 Custom Metal KeyboardsNegotiableMOQ: 1 Set
-
Compact Format Vandal Proof IP65 Customized KeyboardsNegotiableMOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Key-Tek
Model Number
K-TEK-B392TP
Application
Computer Keyboard
Keypad Button Material
Metal
66 keys vandal-proof IP65 terminal keyboard with integrated ruggedized touchpad, with gold-on-gold key switch technology with short stroke 0.45mm, with rear panel mounting solution.
MAIN FEATURE
- Imposing stainless steel design, specially designed keyboards meet the highest demands with regard to design, functionality, longevity and high protection level. We design and manufacture complete electronic modules including controller in close consultation with our customers.
- Stainless steel fascia and key-tops guard willful destruction, vandal-proof, against corrosion, weather-proof especially under extreme climatic conditions, water proof/dirt proof operation under hostile environments.
- Waterproof execution according to degree of protection IP65 from the front panel, the keyboard is sealed against the ingress or liquid and dirt when mounted in a suitable enclosure.
- Internet friendly key layout, key-tops are laser-etched in legends and characters for easy readability, long life to prevent lettering rub-off.
- Metal keys are protected against twisting and levering which can not be dislodged from front, or defaced removing key covers.
- With firm tactile key feel, short key travel 0.45mm switches.
- Ease of customizing with multiple languages, to accommodate foreign or custom variants.
- Easily mounting into enclosure or panel, and is provided with PS/2, USB connection output cables that plug directly into the host computer for normal keyboard operations.
MECHANICAL DATA
- Key top style: Plain/Non-Protuberant rectangular keys, raised Braille on keys and etched graphics are available
- Touchpad cover: Composite
- More than Lifetime 10 million strokes
- Mutual Capacitance sensing
- X/Y position sensing resolution: 40 counts/mm
- X/Y position reporting: Relative
- Output (self-detectable depending on cable): PS2 or USB
- Tracking speed: Maximum 1,016 m/sec
- Power supply voltage: 5 VDC ±0.25V
- Current rating (active mode): 17 mA
- Front Plate: Super quality brushed stainless steel
- Short key travel: 0.45mm
- Switch Life: more than 5 million operations.
- Actuation Force: 2.0N+/-0.1N for key 14.0mm x 14.0mm (pressure point), 4.0N+/-0.1N for key 14.0mm x 28.0mm (pressure point)
- Lettering: Sunk laser legends & characters in high quality ink
- Actuator/keys materials: stainless steel
- G.W.:1.80KGs
- Dimensions: 392.0mm x 110.0mm (front panel), 416.0mm x134.0mm (back panel)
ELECTRICAL DATA
- Supply Voltage: +5V DC +/-5%
- Current Rating: appr. 20mA
- EMC Standard: It is compliance with the council EMC directive 89/336/EEC EN55022: 1988+A1:2000+A2:2003 EN55024: 1988+A1:2001+A2:2003
- Emission: EN 50081-1
- Immunity: EN 50082-1
- Lifespan> 5 years
- Switch Contact Material:Gold-on-Gold key switch technology with metal dome PCB.
- Interface: PS2, USB available.
- OS: DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/Win7, Linux, Unix, Mac OSX
ENVIRONMENTAL ADAPTABILITY
- Operating temperature:-20oC to +60oC
- Storage temperature: -30oC to +70oC
- Operating RH: 30-90%
- Atmospheric pressure: 60-106Kpa.
- Saline mist: 96 hours, IEC 60512-6
- Damp heat test at +40oC: 21 days, IEC 60512-6
- Dry heat test at +85oC: 10 days, IEC 60512-6
RELIABILITY
- RoHS Compliant, CE and FCC
- Protection Level: IP65(front panel)
- Vandal resistant IK10
- Key Lifespan >5 million actuations
- Touchpad lifespan > 10 million of times
- MTBF >50000H
- MTTR <30min
