IP65 industrial slim metal usb numeric 4x4 keypad for mini device
Model NO: K-TEK-B75KP
Dimension: 75.0mm x 73.0mm (Front Panel)
Description: 16 keys MINI vandal proof IP65 dynamic Stainless Steel numeric keypad with industrial metal dome PCB electronics controller shieded & protected by stainless steel housing, gold-on-gold key switch technology with short stroke 0.45mm with tactile feeling for stable and accurate data input, stainless steel top plate with threaded bolts under top stainless steel plate for top panel mounting solution.
MAIN FEATURE
Stainless steel fascia and key-tops guard willful destruction, against corrosion, shock, dust, falling raining, splashing,
hose-directed water and vandal resistant, operation under hostile environments.
Internet friendly key layout, key-tops are sunk laser-etched in legends and characters via using high quality ink for easy
readability, long life to prevent lettering rub-off. Or protrusive engraving available.
With firm tactile key feel, short travel switches, with unique double over-travel protection.
Waterproof/dirt-proof execution according to degree of protection IP65/IP54, waterproof and dirt proof encapsulation with
unique membrane.
Easily mounting into enclosure or panel, and is provided with PS/2, connection output cables that plug directly into the host
computer for normal keypad operations.
OS: DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/Win 7, Linux, Unix, Mac OSX
COMMUNICATION PARAMETER
Standard PC/AT keyboard interface.
10mm x 10mm slim key with compact keypad layout.
16 actuator on the keypad: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, B space, Up, Down, Menu, Cancel, Enter, 4 x 4 scanning code. Any keys
can be re-defined per customers’ requirements.
MECHANICAL DATA
Actuation Force: 1.0N +/-0.1N (pressure point).
Key Travel: 0.45mm.
Lettering: laser engraving, or raised letters.
Front panel: brushed stainless steel.
Actuator/keys materials: stainless steel.
Dimensions: 75.0mm x 73.0mm.
G.W. 0.6KGs
ELECTRICAL DATA
Switching material: Gold-on-Gold.
Power supply voltage: 5V DC.
Power Consumption: Under 300mW for operation, under 200mW for non-operation.
Electrical lifetime: > 5 years.
EMC:EN55022(B).
Communication interface: PS2, or USB available.
ENVIRONMENTAL ADAPTABILITY
Operating temperature:-20°C to +60°C.
Storage temperature:-30°C to +70°C.
Operating RH: 30~90%.
Atmospheric pressure: 60~106Kpa.
RELIABILITY
RoHS Compliant, CE and FCC, ESD
Protection Level: IP65(front panel)
Vandal resistant IK10
Key Lifespan >5 million actuations.
MTBF >50000h.
MTTR <30min.
