Movable desktop metal numeric metalic keypad for smart card reader
Dimension:118.0mm x 122.0mm x (18.0 +30.0) mm
Description:17 keys compact format IP65 dynamic vandal proof Stainless Steel industrial numeric keypad with industrial PCB electronics controller shieded & protected by stainless steel housing,industrial PCB with carbon-on-gold key switch technology with long stroke (2.0mm) with extremely good tactile feeling for fast and accurate data input without any noise, movable and stand alone desk top.
MAIN FEATURE
Stainless steel fascia and key-tops guard willful destruction, against corrosion, shock, dust, falling raining, splashing, hose-directed water and vandal resistant, operation under hostile environments.
key-tops are sunk laser-etched in legends and characters via using high quality ink for easy readability, long life to prevent lettering rub-off.
With firm tactile key feel, carbon-on-gold key switches with full long stroke 2.0mm, with unique double over-travel protection.
Waterproof/dirt-proof execution according to degree of protection IP66, waterproof and dirt proof encapsulation with one complete industrial silicone rubber.
Provided with PS/2 or USB, connection output cables that plug directly into the host computer for normal keypad operations.
OS: All windows, Linux, Unix, Mac OSX
COMMUNICATION PARAMETER
USB, PS2 or RS232 interface are available.
17 actuator on the keypad: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, Numeric Lock , +, -, *, / , . , Enter, 4 x 5 scanning code. Any keys can be re-defined per customers' requirements.
MECHANICAL DATA
Switch Contact Material: Carbon-on-Gold key switch technology with gold finish PCB.
Actuation Force: 0.60N+/-0.10N for key 14.0mm x 14.0mm (pressure point), 1.20 N+/-0.1N for key 14.0mm x 28.0mm (pressure point)
Key Travel: 2.0 mm
Lettering: laser engraving, or raised letters.
Front panel: brushed stainless steel
Actuator/keys materials: stainless steel
Dimensions: 118.0mm x 122.0mm x 18.0(30.0)mm
G.W. 1.0KGs
ELECTRICAL DATA
Power supply voltage: 5V DC.
Power Consumption: Under 20mW for operation.
Electrical lifetime: > 5 years
EMC Standard: It is compliance with the council IEC 61000-4-2:2008;IEC 61000-4-3:2006+AI:2007+A2:2010;IEC 61000-4-4:2004
Communication interface: PS2, USB or RS232 are all available.
ENVIRONMENTAL ADAPTABILITY
Operating temperature:-20°C to +60°C
Storage temperature: -30°C to +70°C
Operating RH: 30-90%
Atmospheric pressure: 60-106Kpa.
RELIABILITY
RoHS Compliant, CE and FCC, ESD
Protection Level: IP65(front panel)
Vandal resistant IK09
Key Lifespan >10 million actuations
MTBF >50,000H
MTTR <30min
