Help CenterStainless Steel Keyboard With Encryption PINPAD Supporting DEST and DES
Related Products
-
Vandal Proof Metall Keyboard With Trackball and Integrated EPPNegotiableMOQ: 1 Set -
IP65 Black Backlit Trackball Keyboardl in Factory PriceNegotiableMOQ: 1 Set
-
Vandal Proof Metal Ip65 Keyboard With Trackball and Integrated EPPNegotiableMOQ: 1 Set
-
81 Keys Vandal Proof Compact Format IP65 Short Stroke 0.45mm Stainless Steel KeyboardNegotiableMOQ: 1 Set
-
Black Titanium Industrial Keyboard Price With Track BallNegotiableMOQ: 1 Set
Dimension:340.0mm x 125.0mm (top panel)
Description:79 Keys Vandal proof Compact Format IP65 short stroke 0.45mm Stainless Steel Keyboard with Encryption PINPAD supporting DES/TDES, top panel mounting.
APPLICATION:
This keyboard is mainly targeted for use for unsupervised or semi-supervised positions of varied bank access applications, Bank kiosks, ATM, CDMs etc.
MAIN FEATURE:
Imposing stainless steel design, specially designed keyboards meet the highest demands with regard to design, functionality, longevity and high protection level. We design and manufacture complete electronic modules including controller in close consultation with our customers.
Stainless steel fascia and key-tops guard willful destruction, vandal-proof, against corrosion, weather-proof especially under extreme climatic conditions, water proof/dirt proof, operation under hostile environments.
Waterproof execution according to degree of protection IP65 from the panel, the keyboard is sealed against the ingress or liquid and dirt, when mounted in a suitable enclosure.
The keyboards have an excellent tactile feel with short travel switches. Internet friendly key layout, key-tops are laser-etched in legends and characters for easy readability, long life to prevent lettering rub-off.
Metal keys are protected against twisting and levering which can not be dislodged from front, or defaced removing key covers.
Ease of customizing with multiple languages, to accommodate foreign or custom variants.
The integrated EPP (encryption PINPAD) is with encryption module supporting DES/TDES for bank usage of bank kiosks, CDM/ATM. RS232 interface for EPP.
COMMUNICATION PARAMETER:
Standard RS232 serial interface.
Communication velocity: 19200, 9600, 4800, 2400, 1200bps.
Data format: N, 8, 1.
15 actuators: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, correct, enter, cancel, backup key 2 defined for ABC.
Data encryption and decryption (DES/TDES), MAC Algorithm.
Encryption rate: < 1 second.
MECHANICAL DATA:
Key: 79 keys, super quality brushed stainless steel
Key top style: Non-protuberant rectangular keys, with laser engraved and etched legends and raised braille on keys are available
Front Plate: Super quality brushed stainless steel
key travel: 0.45mm
Switch life: more than 5 million of operations
Lettering: Sunk laser legends & characters in high quality ink
Actuator/keys materials: stainless steel
Actuation Force: 2N+/-0.1N (pressure point).
G.W.:1.60KGs
Dimensions:340.0mm x 125.0mm (front panel), 320.0mm x 105.0mm (back panel)
ELECTRICAL DATA:
Supply Voltage: +5V DC +/-5%
Current Rating: appr. 20mA
EMC Standard: It is compliance with the council EMC directive 89/336/EEC EN55022: 1988+A1:2000+A2:2003 EN55024: 1988+A1:2001+A2:2003
Emission: EN 50081-1
Immunity: EN 50082-1
Lifespan> 5 years
Contact Material: Gold-on-Gold
Interface: PS2, USB available. RS232 for EPP
numeric keypad is with encryption electronics controller supporting DES/Triple DES
OS: DOS/Windows95/98/NT/ME/2000/2003/XP/Vista, Linux, Unix, Mac OSX
ENVIRONMENTAL ADAPTABILITY:
Operating temperature: -20°C to +60°C.
Storage temperature:-30 °C to +70°C.
Operating RH: 30~90%.
Atmospheric pressure: 60~106Kpa.
Keyboard is watertight while being mounted correctly on bank kiosk or ATM/CDM.
RELIABILITY:
RoHS Compliant, CE and FCC
Protection Level: IP65(front panel)
Vandal resistant IK10
Sensitive data can be well saved while sudden power off.
Sensitive data and program can be erased when being tampered.
Key Lifespan > 5 million actuations.
MTBF >50000H.
MTTR <30min.
