Made In China 15kw Marine Diesel Generator Price
- 100 Set / Sets per Month
- Qingdao Port China
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | Ricardo | Model Number: | HQ15GFC |
Output Type: | AC Three Phase | Speed: | 1500/1800 | Frequency: | 50HZ/60HZ |
Rated Power: | 15KW/18.7KVA | Rated Voltage: | 380V | Rated Current: | 27A |
Product Description
Specifications
15kw Marine Diesel Generator Price1>Seawater cooled
2>Brushless alternator
3>One year warranty
4>power from 10kw~500kw
Made In China 15kw Marine Diesel Generator Price
Diesel Generators Standard Configurations | |
1 | Standard High-level quality engine Ricardo series |
2 | Standard High-level quality alternator, Stanford, Brushless, 100% copper wires. Protection Grade: IP23, Insulation Class H. |
3 | No-maintenance start battery |
4 | After acidification under frame, High-level strong |
5 | Electric start, use key start |
6 | Standard control panel Spray-print or LCD show panel |
7 | Daily fuel tank |
8 | High-level shock absorber system |
9 | Ripple flexes exhaust pipe, exhaust siphons, flange, Muffler |
10 | 40°C radiator as standard |
11 | Exhaust silencer |
12 | Charger motor for battery. |
13 | Standard export box |
14 | Manuals |
15 | Tools box |
Generator Ratings
Standy Output(KW/KVA) | Prime Out(KW/KVA) | P.F | Phase | Wires | Size(mm) | Weight (KG) |
16.5/20.6 | 15/18.75 | 0.8 | 3 | 4 | 1600*600*1100 | 550 |
Diesel Engine Data
Engine Model | K4100C |
Cylinder No. | 4 |
Intake Method | Natural Aspiration |
Engine Type | Inline, Direct injection, Four-stroke, water cooling |
Displacement(L) | 3.61 |
Bore*Stroke(mm) | 100*115 |
Engine Max outout(kw/kva) | 30.1/37.6 |
Fuel consumption(g/kw.h) | ≤3.6L/h |
Start Method | DC 12V |
Manufacture | Ricardo/Weifang |
Alternator Data
Alternator Model | XN184ES/XINGNUO STANFORD |
Alterantor Capacity | 15KW/18.75KVA |
Voltage(V) | 110/220 230/400 |
Speed | 1500/1800 |
Excitation Method | Brush/Brushless |
Power Factor | 0.8 |
Frequency (HZ) | 50/60 |
The specification of alternator:
Brand | Stamford, Leroy semor, Maraton and chinese alternator etc. |
Regulator | AVR automatic voltage regulating |
Excite type | pret or shunt |
Connecting type | 3PH star, 3PH-DELTA |
Steady frequency change | 0-5% |
No load voltage | ≥95%-105 |
Steady voltage | ≤±1 |
Insulation degree | H degree |
Exclosure degree | IP23 |
We specialized in producing diesel generator. We have exported to many countries and widely used in domestic.
1. Exported countries: Nigeria, Indonesia, Malaysia, Philippine, North Korea, Ghana, Gabon, South Africa, Guinea, Russia, Iraq, Iran, Colombia, Burkina Faso, Liberia, Zambia, etc.
2. Domestic: Send to most of the cities in china, and get high praise from our clients.
1.What's your power range of Generators?
Answer: We can offer the range from 10kva~1000kva.
2.What's your delivery time?
Answer: Generally,we can delivery in 7 days after we get the deposit.
3.What's your payment?
Answer: We accept T/T ,and 30% as the deposit,the balance payment should be paid before shipping.
4.What's your warranty?
Answer: All our products we offer on year warranty.
5.What's your MOQ?
Answer:We accept the MOQ is 1 set.
