Home > Products > Powered by Ricardo Engine > factory sale!3 phase 30kva electric equipment
factory sale!3 phase 30kva electric equipment
- 10000 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shandong, China | Brand Name: | Ricardo | Model Number: | HQBL30GF |
Output Type: | AC Three Phase | Speed: | 1500/1800 | Frequency: | 50/60hz |
Rated Power: | 30kva | Rated Voltage: | 220/380 | Rated Current: | 54A |
Product Description
factory sale!3 phase 30kva electric equipment
Generators Diesel Standard Configurations | |
1 | Standard High-level quality engine Ricardo series |
2 | Standard High-level quality alternator, Stanford, Brushless, 100% copper wires. Protection Grade: IP23, Insulation Class H. |
3 | Maintenance-free starting battery |
4 | Acidification under frame, High-level and strong |
5 | Electric start, use key start |
6 | Standard control panel Spray-print or LCD show panel |
7 | Daily fuel tank(optional) |
8 | High-level shock absorber system |
9 | Ripple flexes exhaust pipe, exhaust siphons, flange, Muffler |
10 | 40°C radiator as standard |
11 | Exhaust silencer |
12 | Charger motor for battery. |
13 | Standard export box |
14 | Manuals |
15 | Tools box |
Genset model | HQ30GF |
Type | open or sound proof |
Genset output power | 30kva |
Rated voltage | 220/380V,230/400V,240/415V,120/240V |
Frequency | 50/60HZ |
Power factor | 0.8 |
Rated speed | 1500/1800rpm |
Output type | AC three phase/single phase |
Motor | brushless/brush |
Frequency | <3% |
Frequency at stable state: | <0.5% |
Frequency deviation at instantaneous state | ≤+10% |
Frequency return time | ≤3s |
Voltage deviation at stable state | ≤±1% |
Voltage deviation at instantaneous state | ≤+20% |
Voltage return time | ≤4s |
Voltage modulation | ≤0.3% |
The specification of cummins engine:
Model | K4100D |
Cooling Method | water cooled |
Rotating speed | 1500/1800rpm |
Governor system | electrical or mechanical governor |
Aspiration mode | natural aspirated or turbocharged |
Starting method | 12V DC electric starting |
Stroke | 4stroke |
The specification of alternator:
Brand | Stamford, Leroy semor, Maraton and chinese alternator etc. |
Regulator | AVR automatic voltage regulating |
Excite type | Brushless |
Connecting type | 3PH star, 3PH-DELTA |
Steady frequency change | 0-5% |
No load voltage | ≥95%-105 |
Steady voltage | ≤±1 |
Insulation degree | H degree |
Exclosure degree | IP23 |
Diesel Engine---Ricardo
Ricardo diesel generators, adopting diesel engines as power, which are manufacturers introducing British Ricardo technology, bear the features of compact structure, convenient operation, stable operation, low fuel consumption, low emission and low noise. Each performance indicator has reached National standard JB/T8981-1999, also meeting international standard IEC34-1. The product is widely used in numerous industries, including highways, telecommunications, hospitals, securities companies, high-rise buildings, public security, transportation systems, television station and etc.
We can offer Ricardo series diesel generators from 24kw to 150kw
1. High-strength alloy cast cylinder block and cylinder head, whole balance structure forged by overall distortion and fillet hardening crankshaft, provides high strength and operation in balance.
2. DC 24V electric start, charging alternator, electronic adjustment system, performance better than that specified in GB/T2820.5 and ISO8525-5.
3. Four-valve per cylinder design, direct injection; turbocharged technology, applying advanced Holset exhaust gas turbocharger; good altitude adaptability, without impairment of output power under the altitude of 1525m.
Huaquan provides a full line of brand new and high quality products.Each and every unit is strictly factory tested Warranty is according to our standard conditions:12 months or 1000 running hour’s ,subject to the earlier one .Service and parts are available from our factory.
We specialized in producing diesel generators. We have exported to many countries and widely used in domestic.
1. Exported countries: Nigeria, Indonesia, Malaysia, Philippine, North Korea, Ghana, Gabon, South Africa, Guinea, Russia, Iraq, Iran, Colombia, Burkina Faso, Liberia, Zambia, etc.
2. Domestic: Send to most of the cities in china, and get high praise from our clients.
1.What's your power range of Generators?
Answer: We can offer the range from 10kva~1000kva.
2.What's your delivery time?
Answer: Generally,we can delivery in 7 days after we get the deposit.
3.What's your payment?
Answer: We accept T/T ,and 30% as the deposit,the balance payment should be paid before shipping.
4.What's your warranty?
Answer: All our products we offer on year warranty.
5.What's your MOQ?
Answer:We accept the MOQ is 1 set.
