Home > Products > Powered by Ricardo Engine > Weichai Steyr series engine AC output ,As One Main Power Generator 200kva
Weichai Steyr series engine AC output ,As One Main Power Generator 200kva
- 300 Set / Sets per Month
- Qingdao
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | Huaquan | Model Number: | HQBL200GF |
Output Type: | AC Three Phase | Speed: | 1500/1800 | Frequency: | 50/60 |
Rated Power: | 200kva | Rated Voltage: | 110/220 230/400 | Rated Current: | 360 |
Product Description
200KVA Generator
Our Features:
Weifang Huaquan Power is the professional manufacturer of generators. We specialized in producing diesel generator, Power generators, and engine generators for many years.
1. Offer the main Power range from 10kva~1500kva.
2. Adopt the famous engines like Weichai engines, Deutz engines, Steyr engines, Cummins engines, Perkins engines, Isuzu engines, Ricardo engines, Changchai engines, Yuchai engines, Jichai engines etc. These are widely used all over the word.
3. We only adopt standard high-level quality alternator, to produce the high-level diesel generators.
4. We offer Open-generators, Silent-Generators, Automatic-Generators and Trailer-Generators.
5. All spare parts serviced directly by our company.
6. We are confirmed as the OEM factory by many those engine factories and alternator factories.
Our Generator Standard configurations:
1.Standard High-level quality engine Ricardo series.
2.Standard High-level quality alternator, Stanford, Brushless, 100% copper wires. Protection Grade: IP23, Insulation Class H.
3.No-maintenance start battery.
4.After acidification under frame, High-level strong.
5.Electric start, use key start.
6.Electric throttle.
7.Standard control panel Spray-print or LCD show panel.
8.Daily fuel tank.
9.High-level shock absorber system.
10.Ripple flex exhaust pipe, exhaust siphons, flange, Muffler.
11.40°C radiator as standard.
12.Exhaust silencer
13.Charger motor for battery.
14.Standard export box.
15.Manuals.
16.Tools box.
,
Options Parts
1.Soundproof box (Silent), noise level less than 65DB.
2.Full automatic with LCD display show panel(Contain AMF and ATS system)
3.Trailer model, with mobile wheels or options Rainproof, Canopy etc.
Our experience
We specialized in producing diesel generator for many years. We have export to many countries and widely used in domestic.
- Exported countries: Nigeria, Indonesia, Malaysia, Philippine, North Korea, Ghana, Gabon, South Africa, Guinea, Russia, Iraq, Iran, Colombia, Burkina Faso, Liberia, Zambia, etc.
- Domestic: Send to all the cities in china, and get good praise from my clients.
The below is our delivery site send to abroad and domestic.
Ricardo Diesel Generator Features
Genset Model | Prime Powe | Standby Power | Engine | Fuel Consumption | Cylinder No. | Size | Weight | ||
KW | KVA | KW | KVA | (L/h) | L×W×H(mm) | (KG) | |||
HQBL20GF | 20 | 25 | 22 | 28 | K4100D | 4 | 4 | 1600×600×1100 | 520 |
HQBL30GF | 30 | 37.5 | 33 | 41 | K4100D | 6 | 4 | 1600×600×1100 | 600 |
HQBL40GF | 40 | 50 | 44 | 55 | K4100ZD | 8 | 4 | 1700×600×1300 | 800 |
HQBL50GF | 50 | 62.5 | 55 | 69 | R4105ZD | 11 | 4 | 1800×700×1300 | 1600 |
HQBL60GF | 60 | 75 | 66 | 82.5 | R6105ZD | 13 | 6 | 2250×720×1500 | 1700 |
HQBL75GF | 75 | 93 | 82.5 | 103 | R6105ZLD | 15.5 | 6 | 2250×720×1600 | 1750 |
HQBL100GF | 100 | 125 | 110 | 156 | 6105AZLD | 21 | 6 | 2300×720×1600 | 1800 |
HQBL120GF | 120 | 150 | 132 | 165 | 6105IZLD | 23.8 | 6 | 2300×730×1600 | 1900 |
HQBL150GF | 150 | 187 | 165 | 206 | 6113ZLD | 30 | 6 | 2450×800×1600 | 2200 |
HQBL200GF | 200 | 250 | 220 | 275 | 6126ZLD | 40 | 6 | 2800×800×1800 | 2900 |
|
|
|
|
|
|
|
|
|
|
Our service
Huaquan Power offer full line diesel generators to abroad and domestic. Each unit generator tested in factory at least three times by experienced engineer before been delivered. First tested when finished production. Second tested when send to our store. Third time tested before delivery by experience engineer, to check every where will be ok then send to the destination places.
Our all generator offer one year warranty or Running 1000 hour’s.
All spare parts offered directly from the factory, with low price, let you keep it as spare parts.
