OEM High quality silent type generator 500kva, water cooled silent diesel generator 500kva
| Technic Data of Genesets | |||||
| Model of Generating Set | HQC400GF | ||||
| Brand of Engine | COPY CUMMINS | ||||
| Rated Output Power/Prime Output Power (KW) | 400/504 | ||||
| Rated Output Capacity/Prime Output Power (KVA) | 500/630 | ||||
| Power Factor COSΦ | 0.8 (lag) | ||||
| Frequency(Hz) | 50/60 | ||||
| Output Voltage(V) | 400/230 | ||||
| Rated Output Current/Standby Output Current(A) | 720/907.2 | ||||
| Open Type Generator Set Dimension(L*W*H)(mm) | 4500*1600*2250 | ||||
| Generator Set Net Weight (kg) | About 4200kg | ||||
| Diesel Engine | |||||
| Model | KTA19-G4 | Intake type | Turbocharge | ||
| Rotate Speed(rmp) | 1500/1800 | Cylinder Bore/Stroke(mm) | 6-159*159 | ||
| Compression Rate | 18:1 | Total Displacement (L) | 19 | ||
| Rated Fuel Consumption (g/KW.h) | 195 | Frequency Control Ways | Electric | ||
| Alternator | |||||
| BRAND | STAMFORD | Model | STAMFORD | ||
| Voltage Regulation Mode | AVR | Ways of Excitation | Brushless self-excited | ||
| Insulation Grade | H | Over Speed Capacity | 2250min-1 | ||
| Protection Grade | IP23 | Cooling Mode | Wate- cooled | ||
| Efficiency | 95.1% | EMI Coefficient | THF<2%,TIF<50 | ||
| Intelligent LCD controller | |||||
| Brand | Smartgen |
Model | SMARTGEN |
||
A: Test before shippment
- Each Generator Set shall be put into commission more than 4 hours totally, tested on idle load, fully load and 10% overload.
- Noise level shall be tested.
- All of the meters on the control panel shall be tested.
- The appearance of the Set and the label, nameplate shall be tested. "
-Voltage available: 50Hz: 380-400-415V/ 220-230-240V; 60Hz: 220-380-416-440-480V/ 110-208-220-240V. Any special voltage is also available as cilent's request
C: Control System:
1, Basic control system, the basic type control system is provided with a current meter, a volmeter, a frequency meter, an oil pressure guage, a water thermometer and indicator lights on the control cabinet and 4 additional protection fuctions are to be provided as required by customers.
2, AST (Automatic Start Type Control System), Optional Automatic Start Type System is provided When there is an interruption in the commercial power supply (or there is a start signal in other generator sets), this generator set will, subject to time delay acknowledgement (0-30 S adjustable), be automatically started (1-8 times adjustable). In addition, it is provided with a basic protection function and digital or meter indication of voltage, current, frequency and rotation speed parameters.
3, ATS (Automatic Transfer System), The optional system is provided with a fully automatic transfer switch, a control electric apparatus and an indicator light on the control panel and is coordinated with an automatic type contral cabinet, thus serving the fuction of automatic changeover between the power supplied by the grid and the power generated by the genset.
4, Sync Parallel Control System, this control system can connect 2 or 3 or 4 gensets to make more larger power. such as: if you want 1000kw power, you can choose 2 sets 500kw gensets to work together, using this control system can make 1000kw power.
1.Huaquan Power offer complete lines generator after sale service. We offer 1 year or 1000 hours runing time for warranty.
2.We offer technical support for free all the time.
3.We offer the spare parts for our generators all the time,any time you can contact us for spare parts.
Q1: How is your Package & Payment & Delivery Date & Warranty?
A.1) Package: Plastic film (free of charge) or wooden case (add USD200 for wooden)
A.2) Payment: by 30% T/T as deposit, 70% balance should be paid 10 days before shipment. Or 100% L/C at sight.
A.3) Delivery: 7-25 days after we get the down payment.
A.4) Warranty: Guarantee for one year or 1000 running hours (whichever come first shall apply) from installed date. During the guarantee period. such as Cummins or Perkins generators. they are international brands and the after-sale service is worldwide. you can contact your country's after-sale or contact us for repairment. when replacing spare parts, please kindly take some pictures to describe the problems. we will solve it a.s.a.p.
Q2: Any advantages about your company?
Answers: KD Brand Diesel Generators with following advantages:
----MOQ is 1 set and we could finis more than 100sets/month
---- Middle-high Positioning;
---- 7-25days Lead-time;
---- Got the ISO and CE certificate; OEM Certifications
---- High quality with the best price can help you get more benefit and beat your competitors;
---- Powered by Cummins, Perkins, Detuz etc. famous engine brands optional;
---- Open, Soundproof Canopy, Container, Trailer etc. for your choose.
Q3: Any advantage of Digital Control Panel?
1) Controller Brand: Smartgen, Deepsea,ComAp
2) Control Panel: English interface,LED screen and touch buttons.
3) Main Functions:
1- Display loading power, voltage, current, frequency, speed, temperature, oil pressure, running time etc.
2- Warning when low or high voltage, low or high frequency, over current, over or low speed, low or over battery voltage etc.
3- Over load protection, over/under frequency protection, over/under/imbalance voltage protection, and low oil shutdown
