3D design drawing
Electric Single Girder 10 Ton Overhead Crane With Electric Hoist
-----------------Best Solutions Ready For Installation To Meet Individual Requirements
Europe type beam travelling bridge crane
Based on connect and assimilating foreign advanced technology, this type of crane takes modular design theories as guidance, uses modern computer technology as means, introduces optimized and reliable design methods, which is new type of crane made by employing import configuration, new material and technology has features in light-weight, generalizing, energy-conservation and environmental protection, maintenance free and high technology content.
Design international standard: DIN (Germany), FEM (Europe), ISO (International)
1.Light dead weight,
2.Small occupied space,
3.High working performance,
4.Easy operation,
5.Safe and reliable,
6.Low operation and maintenance costs.
Application:
The Europe type overhead crane widely used in machinery manufacture, metallurgy, petroleum, petrifaction, port, railway, food, paper making, construction, electronics industries workshop, warehouse and other material handling situations, esp. applied to material handling that need precise positioning, large components precise assembly situation.
Advantages and features of Europe type overhead crane
1. Particular compact main beam structure,computer optimized design box type girder ,strong rigidity, light dead weight, which could effectively save your factory space and investment cost.
2. Low headroom trolley hoist.
3. Unique wheel frame design, stable structure.
4. Protection class is IP54, F class insulation.
5. Specially designed gearbox for crane, adopts oblique gears, self lubrication.
6. Various traveling speed
7. Variety of patterns meet customers needs, Sub-assembly characteristic are tested before assembly.
Advantages and features of adopting Europe type electric hoist
1. Europe working system makes crane with long service lifetime and higher working efficiency.
2. The various lifting speed and trolley traveling speed prompted handling efficiency.
3. Traveling speed adopts stepless speed adjustment control
4. Small hook compact size, high utility rate of space.
1. Limit Switch: Safety limit switches for stoppers prevent over traveling in all motions.
2. Anti collision device
When two crane traveling on the same rail, the cranes will install the following devices:
Anti-collision device, Infrared non-contact and inductive type limit device
Sound and light alarm device, Wireless anti-collision device
3. Weight overload protection device
Includes automatic stopping type lifting weight limiter and weight display device.
4. Lifting limit switch and traveling limit switch
5. Emergency stop system
6. Electrical protection
The main insulation switch, emergency stop switch, short circuit, Zero voltage protection, loss of field protection, Current overload protection, over speed protection, zero position protection
Phase sequence protection and adopted crane specially anti- vibration contactor etc.
7. Interlock device
It sets interlock device for the cabin door and the other door from cabin into bridge structure, when the door is opened, the crane cannot work.
Normal Quotations:
1. Lifting capacity ______ton
2. Single beam or double beam?
3. Standard type or Europe type?
4. Crane Span _______meters (Rail middle center to center distance)
5. Lifting height ______meters (Hook to ground)
6. Industrial voltage _____V, _____HZ, 3Phases
7. Control mode
A. Pendant control B. Remote control C. Cabin control
8. What material does the crane lift?
9. Do you also need us to supply bearing beam, rail and slide wire?
A. Yes B. No
10. Any special design demand on crane?
