Specifications
1>silent diesel generator2>low fuel consumption
3>Competitive Price
4>Free of charge spare parts
5>LCD control panel
Global hot sale family use silent diesel generator
| Diesel Generators Standard Configurations | |
| 1 | Standard High-level quality engine Cummins/Ricardo/Isuzu/Deutz series |
| 2 | Standard High-level quality alternator, Stanford, Brushless, 100% copper wires. Protection Grade: IP23, Insulation Class H. |
| 3 | No-maintenance start battery |
| 4 | After acidification under frame, High-level strong |
| 5 | Electric start, use key start |
| 6 | Standard control panel Spray-print or LCD show panel |
| 7 | Daily fuel tank |
| 8 | High-level shock absorber system |
| 9 | Ripple flexes exhaust pipe, exhaust siphons, flange, Muffler |
| 10 | 40°C radiator as standard |
| 11 | Exhaust silencer |
| 12 | Charger motor for battery. |
| 13 | Standard export box |
| 14 | Manuals |
| 15 | Tools box |
Genset model |
HQ |
Type |
open/sound proof/weather proof |
Genset output power range |
5KVA-300KVA |
Rated voltage |
220/380V,230/400V,240/415V,120/240V |
Frequency |
50/60HZ |
Power factor |
0.8 |
Rated speed |
1500/1800rpm |
Output type |
AC three phase/single phase |
Motor |
brushless |
Frequency |
<3% |
Frequency at stable state: |
<0.5% |
Frequency deviation at instantaneous state |
≤+10% |
Frequency return time |
≤3s |
Voltage deviation at stable state |
≤±1% |
Voltage deviation at instantaneous state |
≤+20% |
Voltage return time |
≤4s |
Voltage modulation |
≤0.3% |
The specification of alternator:
Brand |
Stamford, Leroy semor, Maraton and chinese alternator etc. |
Regulator |
AVR automatic voltage regulating |
Excite type |
pret or shunt |
Connecting type |
3PH star, 3PH-DELTA |
Steady frequency change |
0-5% |
No load voltage |
≥95%-105 |
Steady voltage |
≤±1 |
Insulation degree |
H degree |
Exclosure degree |
IP23 |
Sielnt Generator
1.Direct injection combustion chamber, high efficiency, low noise.
2.Dual intake and exhaust structure to avoid the generation of turbulence, making the intake and exhaust more smoothly.
3.Significant thickening of the ultra-quiet generator soundproof pads, have a stronger noise reduction capabilities.
Large cabinet size increases the internal space of the unit, soundproof space between the pad and the chassis was also significantly broadened, so as to achieve superior noise reduction.
4.Noise reduction standards with ISO3744 requirements, adapt to urban environmental requirements silent type casing, the noise can be reduced to 65-75db cases the following.
5.Dedicated muffler noise reduction materials, greatly inhibited the mechanical noise.
6.Damping measures to ensure efficient operation of the unit balance.
7.Scientific observation window and emergency stop buttons for easy operation and observation running.
8.Series and good ventilation to prevent heat radiation measures to ensure that the unit is always working in a suitable ambient temperature.
9.Large capacity base fuel tank, continuous operation for 8 hours.
10.Beautiful appearance, reasonable structure
11.Sealing, fully enclosed cabinet, 2mm steel plate made of rain, snow, dust, able to work in harsh environments
13.Lifting convenience, the unit in order to facilitate transport in the box set 4 lifting device
Huaquan provides a full line of brand new and high quality products.Each and every unit is strictly factory tested Warranty is according to our standard conditions:12 months or 1000 running hour’s ,subject to the earlier one .Service and parts are available from our factory.
We specialized in producing diesel generator for many years. We have exported to many countries and widely used in domestic.
1. Exported countries: Nigeria, Indonesia, Malaysia, Philippine, North Korea, Ghana, Gabon, South Africa, Guinea, Russia, Iraq, Iran, Colombia, Burkina Faso, Liberia, Zambia, etc.
2. Domestic: Send to most of the cities in china, and get high praise from my clients.
1.What's your power range of Generators?
Answer: We can offer the range from 5kva~1000kva.
2.What's your delivery time?
Answer: Generally,we can delivery in 7 days after we get the deposit.
3.What's your payment?
Answer: We accept T/T ,and 30% as the deposit,the balance payment should be paid before shipping.more than $2000 can use L/C.
4.What's your warranty?
Answer: All our products we offer on year warranty.
5.What's your MOQ?
Answer:We accept the MOQ is 1 set.
