3D design drawing Customizable 3P 4P 6P Seamless Sliding Contact Line Supply Power for Overhead Crane
We can also supply the main crane components and Full Manufacturing Drawings and Full Technical support,and Your Side Manufacturing the beam structure in your country,That will save your sea freight and transportation cost.
-------------Best Solutions Ready For Installation To Meet Individual Requirements
OLAT Cranes power supply lines and conductors are extremely rugged systems for supplying power and control signals to mobile equipment.They feature high transmission reliability and ease of installation and maintenance,both for cranes as well as rail-mounted machinery.In harsh outdoor operating conditions and in dusty working environment.
Depending on requirements,OLAT Cranes power supply lines and conductors can be supplied in various designs with different numbers of poles.
OSLK Series Crane Safety Sliding Lines overview
OLAT Cranes OSLK Series Crane Safety Sliding Lines are power-supply solutions for mobile consumers such as cranes and monorails.They offer a high level of safety and versatility for easy installation and conversion.Further strengths include:
»Light,compact desigh
»Space-saving power supply line
»High electrical safety
»Reliable power supply
»Convenient maintenance
»Variety of suspension possibility
—————————————————————————————
Detailed Introduction
»Great versatility
•Variety of suspension arrangements, combined suspension fitting
•Light, compact design
•Universal suspension can be fitted on profile sections and C rails
•Snap-on connection – e.g. for perforated sheet or drilled girder web
•Single suspension for variable center distance
•Suspension distances up to 9.8 ft.
•Straight end sections can be cut by hand – no need for additional preparation of joints
(cut-outs, drilling, etc.)
•Isolating sections, powerfeeds and transfer sections can be quickly fitted and changed
on-site
»High safety and reliability
•Safety busbar line with IP 23 protection against accidental contact for horizontal
installation
•Reliable power transmission by current collector pantographs
•High electrical safety due to large spacing between conductors and variable center
distance for single suspension
•Expansion joints between all conductor sections absorb differences in length caused by
temperature variation
•Corrosion resistance
»Convenient assembly and maintenance
•Simple installation thanks to prepared assemblies
•Bolted suspension, compact dimensions
•Easily maintained as conductors and current collectors are visible
OLAT Cranes OSLK Series Crane Safety Sliding Lines is an ergonomic solution for mobile electric equipment including cranes, trolleys, traveling electric tools and other appliances. OSLK Series Crane Safety Sliding Lines is effective for a wide range of applications due to its high thermal and mechanical strength provided by its aluminum enclosure.
»High electrical safety with separate insulators
»Split enclosure provides good access to the conductors
»Simple installation thanks to prepared assemblies
»Simple installation of electrical signal and pulse generators
»Corrosion resistance
»Safety conductor line offers protection against accidental contact
——————————————————————————————————————
OSLK Series Crane Safety Sliding Lines crane power feeding line or conductor bar is a special conductor system that provides electricity to mobile and rotary equipment. Typically comprised of electrical conductor and collector, this conductor system finds wide applications in crane industry. Two most commonly used forms of conductor system are: enclosed and parallel.
»Installation and maintenance is simple and straightforward.
»Safe, reliable even in the harshest climates such as heavy rain, snow, for frost.
»Great electrical conductivity while dissipating heat quickly.
»Low impedance, minimum line loss.
»Graphite brush with high electrical conductivity and wear resistance
»Long use life
OLAT Crane Power Supply - OSLK Series Single Conductor Power Supply
OSLK Series single conductors are power-supply solutions for mobile consumers such as cranes and monorails. They offer a high level of safety and versatility for easy installation and conversion.
»Excellent versatility
•Applicable in many different applications due to high thermal and mechanical strength
provided by its aluminium enclosure
•Light and compact design
»High safety and reliability
•Safety conductor line for protection against accidental contact
•High electrical safety with separate insulators
•Corrosion resistance
»Convenient assembly and maintenance
•Split enclosure provide access to the conductors
•Simple installation due to standardized assemblies
—————————————————————————————
Installation of OSLK Series Crane Safety Sliding Lines
---------------------Various of installation methods to meet every individual requirements,Guarantee the safety of using.
OSLK Series Crane Safety sliding contact line is made up of electrolytic copper ,aluminum,after pressing a H shaped materials ,through special process to deal with the strength appearance ,in order to ensure the service life of slide wire stainless steel embedded in a H shaped aluminum ,as sliding contact with the collector conductive wear-resisting surface.
01.OLAT CARNE OSLK SERIES SINGLE-STAGE COMBINED SLIDING LINES TECHNICAL PARAMETERS
| Specification | Sectional Dimension(mm) | Carrying Capacity(A) | ||
| A | B | C | ||
| OSLK-150/200 | 26.5 | 20.0 | 7.0 | 200 |
| OSLK-250/400 | 42.0 | 32.5 | 10.0 | 400 |
| OSLK-400/600 | 42.0 | 32.5 | 10.0 | 600 |
| OSLK-500/800 | 42.0 | 32.5 | 10.0 | 800 |
| OSLK-700/1000 | 42.0 | 32.5 | 10.0 | 1000 |
| OSLK-900/1250 | 42.0 | 32.5 | 10.0 | 1250 |
| OSLK-1500/2000 | 65 | 50 | 12 | 2000 |
| OSLK-2000/2500 | 85 | 60 | 15 | 2500 |
| OSLK-1600/2000 | 91.7 | 55 | 15.6 | 2000 |
| OSLK-2500/3000 | 91.7 | 55 | 15.6 | 3000 |
02.OLAT CRANE OSLK SERIES SINGLE-STAGE COMBINED SLIDING LINES TECHNICAL STANDARDS
| Specification | OSLK-150 | OSLK-200 | OSLK-300 | OSLK-400 | OSLK-500 | OSLK-800 | OSLK-1300 |
| Rated current(A) | 150 | 200 | 300 | 400 | 500 | 800 | 1300 |
| +35℃ current resistance (Ω/m) | 0.000412 | 0.000354 | 0.000293 | 0.000212 | 0.000127 | 0.000083 |
0.000063 |
| Truck gauge is 80mm truck resistance(Ω/m) | 0.000528 | 0.000413 | 0.000326 | 0.000228 | 0.000163 | 0.000148 | 0.000122 |
| Running voltage(V) | 600V/AC or 600V/DC | ||||||
| Insulating sheath bearing Max.voltage(KV) | 13.9 | ||||||
| Insulator surface resistance(Ω) | 2×1013 | ||||||
| KC(Comparative tracking index) | >600V | ||||||
| Max. traveling speed(m/min) | 600 | ||||||
| Suitable temperature(℃) | -35℃—+55℃ | ||||||
| Combustible of insulating material | Self extinction | ||||||
| Suspension space(m) | 1.5m/3m 1.33m/4m 1.5m/6m 2m/6m | ||||||
| Rail section expansion |
If the length of installation is more than 200m need to consider (Installaion length under 200m without consider ) |
||||||
| Standard length of rail(m) | 6m(or as your demand) |
||||||
| Anti-corrosion | Acid and Alkali resistance etc. |
||||||
| Cass protection class | IP23 | ||||||
| Anticorrosion electricl grade | 1 Grade | ||||||
OLAT Crane OSLK Series Single-Stage Combined Sliding Lines Packaging & Shipping
Variety of packaging methods,Sliding Lines are packaged in a wooden box after being wrapped by plastic film.To guarantee the safety of Sliding Lines.Improving the using efficiency of client.
OLAT CRANE Factory Real situation At a Glance
—————————————————————————————
————————————————————————————
