low water pump pressure switch

Specifications

low water pump pressure switch
Suitable for
water & gas & air & oil etc.
Adjustable pressure range: Vacuum -100 to +100KPa

low water pump pressure switch

Advantages:
fessional skill
2.Specific products
3.Tailored cost-effective production for our customers

Technical Parameter:



1, Switching type : SPST NC  & SPST NO( Selectable),

    Switch frequency & Response time: 60 Cycle /min, ≤100ms.

2, Pressure fitting: M14X1-6g( Male ) & 1/8"-27NPT( Femal) .

3, Electrical connection:   227 IEC 52 2X0.5mm² Lead wire .

4, Voltage: 5-110VDC, 5-250VAC;

     Resistance load : 0.1A to 3,  Inductive load : 0.1A to 1A

5, Fluid media: water &  gas & air & oil etc.

6, Work Life: ≥100,000 Cycle.

7,  Protection class : IP00.

8, Ambient temperature: -40°C~65°C(Selectable),

    Medium temperature: -10°C~100°C(Selectable). .

9, Model: ( Selectable ).

10,Working pressure: Vacuum 100KPa to +100KPa (Selectable).

After-sales service:
              We promise to carry out the following after-sales service:
       Warranty: The warranty period is 12 months starting from the shipping date.
 The rate of Production Quality Problem is lower to 100PPM, replace the bad for free

Certificate:

Production Photo:





Dimension Drawing:
