UHT Sterilizer Hy-Filling

Company Instruction:

Located in Zhangjiagang City of Suzhou, the Yangtze River Delta, our company has 50million RMB fixed assets, covers an area of 30,000 square meters, with a more than 30 professionals team to design and develop, is a key professional enterprise, which integrates development, research, design, manufacture, technology service and marketing, to manufacture complete sets of wine, beverage and sticky filling equipments.

We are adhering to the principle of "market-oriented, quality as the main line, service as the guarantee and repute as the basis". HY-Filling follows ISO9001:2000 international quality management system, it has established and improved the quality assurance system to ensure the quality and performance of the company's products. The Development department of HY-Filling, with advanced technologies, has more than 30 full-time design and development engineers. HY-Filling's technologies mainly sources from Italy, France, Germany, Switzerland and Japan; furthermore, a set of liquid filling production line with advanced technology and high starting-point has been developed combined with China's basic conditions, its high automation level achieved the one in late nineties. Department of After-sale Service of HY-Filling adheres to service goal of "Customers' needs are urgent, customers' requirements are important, customers' satisfaction is the aim", provides the services of equipment installation guidance, products testing, maintenance and spare-parts supplying, consultation, complaints, regular visit every 24 hours.

HY-Filling has a network of customers for the complete set of beverage bottling lines more than 500 which spreads 30 more domestic provinces, municipalities, autonomous regions and the United States, Britain, Japan, the Middle East, Southeast Asia, Africa, Russia, CIS, South Africa etc. Besides the production and sale of equipments, HY-Filling provides various technical services to help users design equipment layout, answer users' consultation, train users' staff and provide practical operation guidance.

Main Product:

· 2000-48000 BPH Mineral Water Bottling Line;

· 2000-40000 BPH Juice Bottling Line;

· 2000-40000 BPH Carbonated Beverage Bottling Line;

· 3000-40000 BPH Beer Bottling Line;

· 6000-30000BPH Aluminium Can Filling Line;

· 120-2000 Barrels/Hour 3-Gallon & 5-Gallon Filling Line;

· Edible Oil Filling Line;

· Aseptic Brick Packing Machine ;

· Aseptic Pouch Packing Machine (Pillow Type);

· PET Preform Injection Machine;

· Bottle Blow Moulding Machine;

· Water Treatment;

· UHT Plant;

· Carbonating Mixer;

· Bottle Unscrambler;

· Film Shrink-wrapping or Carton Box Packaging Machine;

· Pa-Depalletizer;

· Turn Key Project.

UHT

1)      CE certificate

2)      ISO9000: 2000 Certificate

3)      Automatic system

4)      High efficiency, easy maintenance

General description

Ultra High Temperature Sterilizer (UHT) , Pasteurizer

Heat source of the system using the 0.6MPa once saturation steam.

Heating medium of Sterilized material is hot water.

Exiting cooling medium is chilling water.

Chilling medium of recycling product is chilling water.

Touch screen, temperature automatic recorder, electric control components, etc, S. S control cabinet

Equipment description

The tubular sterilizer is the auxiliary equipment for hot filling line. It can be widely applied, especially in high density, acidity and corrosion fibre product. It equipped with CIP and SIP system to meet sterile condition.

Main composition

l  This equipment is composed of tubular heat exchanger, product balance system, steam system, cooling system, electrical cabinet.

l  Tubular heat exchanger is the core equipment and used to do high temperature sterilization, heat recycle and cooling. You can adjust the heat preservation time according to different treated liquid.

l  Product balance system provides constant treated liquid flow and pressure for heat exchanger. It can make sure the sterilizing temperature, time, outlet temperature and flow.  Steam system can provide thermal energy for treated liquid. It can control sterilization temperature via temperature sensor and keep constant sterilization temperature.

l  Cooling system will cool treated liquid into certain production temperature and backflow temperature.

l  Electric cabinet and frame equipped with PLC, electric switch and pneumatic device including all the compressed air valves, switch, air pipes, eclectic relay, flow meter controlling device and control button. Most modules are equipped on the frame, which has adjustable stainless steel legs and pads.

Technical parameters

Installation and commissioning

After the equipments arrived buyer's workshop, the buyer should take it's place for each equipment according to the supplied layout; the seller will send the experienced technician to guide the installation and debugging and trail production, and fulfil the designed capability within the designed time. The installation, debugging and training is about 30-35 days.

Training

The seller will supply technical training to the buyer. The training is includes: equipment structure and maintenance, control and operation. After training, the technicians of the buyer will grasp relevant operation and maintenance skills, and could adjust the technologies more skilled, and can deal with all kinds of malfunction in time.

After-sales service

1) After qualified of the equipment, the seller will supply one year guarantee, control system one year guarantee, free charge for wearing parts, and other spare parts with cost price. Within guarantee period, the technicians who accepted training should strictly obey the requirements asked by the seller to operate the equipments and maintenance, to find the common malfunctions and fault clearing in time; if the technicians of the buyer couldn't solve the problems themselves, the after-sales department will supply long range guide service by phone; if relevant measurements couldn't solve the problems, the seller will send the technicians to the buyer factory, clear the fault or relevant technical problems on site, the charges will reference to the installation and debugging charges.

2) After guaranteed, the seller will supply widely favorable technical support, after-sales service for the lifetime: favorable price for the wearing parts and other spare parts.
