screw conveyor electrical motor

®screw electrical motor designation

Example: GR(F)77-Y1.5-4P-52.07-M2-Ø300-270°-3
GR: R series helical in-line gearmotor
(F): None-shaft output, F-flange output with solid shaft, (SZ-AD)-Input axes type. (R17...R77)- Combined types
77:Gearhead model number
Y1.5: 1.5kw standard electric motor.
4P: 4Pole motor, 2P-2Pole motor, 6P-6Pole motor, 8P-8Pole motor.
52.07: Gear reduction ratio
M2: Mounting way
Ø300:External diameter of output flane (if there is a flange)
270°: Terminal box position
3:Position of cable entry

®conveyor electrical motor parameters

Power range: 0.12-160kW
Output speed(r/min): 0.05 - 809
Output Torque(N.M): Top to 36000N.m

®conveyor electrical motor features

Paint Color: Various
Cooling System: Fan cooler
Noise Level: Low type 65-75 Db
Material: Rugged cast iron or ductile housings
Seals: Nitrile material, dual lipped, double output seals available
Working: 24 hours continuous available and axes forward reverse
Bearing: China standard. But SKF, FAG, NSK, TIMKEN, NTN, KOYO, C&U is a aviable if need
