three phase induction motor

@ three phase induction motor features

1).High standardization and universal of this series, the installation size is basicly similar to Y series motor in the same specification. The standard parts and fasteners are chosen according to relevant national standards.

2).Y2 series (IP54) electric motor adopts special exterior design-parallel & vertical radiate slices. This design not only increased radiate surface but also strengthened the electric motor’s beautification.

3).Y2 series (IP54) motor insulation degree is F grade, but for the temperature rise, we still use B grade standard. It increase both reliability and exterd.

4).Y2 series (IP54) motor has weak vibration and low noise.

5).Y2 series (IP54) motor has the maximun efficency when the loading rate at about 75%.

@ three phase induction motor designation

Electric motor frame from 56 – 355, output range from 0.17HP to 430HP

Motor mounting type B3 (IM 1001), B35 (IM 2001), B5 (IM 3001), B14 (IM 3601), B34 (IM 2101)

Optional voltage 110V, 120V, 220V, 240V, 220/380V, 230V/400V, 380V/660V, 50HZ or 60HZ

Protection type IP44, IP54, IP55 on request

Multiple mounting arrangement for optional

Aluminum frame, end shields and base

Strong cast iron frame

High strength cable

Shaft key and protector supplied

Superior paint finish

45# steel shaft and stainless steel shaft is optional

Electric motor continuous duty S1

Electric motor have vacuum impregnation for insulation

Electric motor is class F insulation and class H insulation is optional

Electric motor has been make according to ISO9001, CE, UL, CCC, GS request

All of our products are make according to GOST, RoHS and IEC standard.

High performance and IE1, IE2, IE3 efficiency
