Home > Products > Top roller-type textile printer > Multicolor rotary digital printing machine with 1.6m width
Multicolor rotary digital printing machine with 1.6m width
- 50 Set / Sets per Month
- Shanghai Port
- T/T
- 2500A cardboard box printing machinery equipment Corrugated cardboard honeycomb cardboard kraft cardboard color inkjet printer
- Top Selling KINGT 1016 Small Flatbed UV Printer For Acrylic KT-board Advertisement sign board printing machine
- Super Discounts KINGT 2513G5 250*130 cm Large Format UV Flatbed Printer Machine Manufacturer Supplier
- OMAJIC digital uv 6090 inkjet printing machine for pen bottle phone case A1 small flatbed inkjet printers
- L1800 DTF Printer Machine
- Wholesale China Printer Black and white multi-function machine N510
Product Details
Condition: | New | Plate Type: | Other, Roller Printer | Place of Origin: | Jiangsu, China |
Brand Name: | DESIGN MLG | Model Number: | EDS-F70 | Usage: | Cloths Printer, Other, Cloths Printer, Roller Fabric Printer |
Automatic Grade: | Automatic | Voltage: | 220V | Gross Power: | 1200W |
Dimensions(L*W*H): | 2620mm*1024mm*1311mm | Weight: | 1000KG | Certification: | CE |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
SPCIFICATION
1.6M format roller fabric printing machine
Epson original printer modified
High Speed and High Color saturation
Product model | EDS-30-RTL | EDS-50-RTL | EDS-70-RTL | |
Head model& Head technology | Epson TFP(thin film piezo),with intelligent dot variable technology | |||
Head No | 1 | 2 | 2 | |
Nozzle Set | one color 720 nozzles | one color 1440 nozzles | one color 720 nozzles | |
Ink color | 4 color (CMYK) | 2*4color(CMYK) | 8 color CMYK LC,LM, orange, blue | |
Output | 2pass,720*720dpi | 29.4m2/h | 52m2/h | 29.4m2/h |
3pass,720*720dpi | 24.5m2/h | No 3pass option | No 3pass option | |
4pass,720*720dpi | 19.5m2/h | 30m2/h | 26m2/h | |
6pass,720*720dpi high resolution mode | 14.7m2/h | No 6pass option |
| |
6pass,720*1440dpi high resolution mode | 7.3m2/h | 14m2/h | 7.3m2/h | |
Ink type | Reactive ink, acid ink(depends on fabric, normally use reactive ink) | |||
Fabric type | Roll cotton, silk, cashmere etc natural fabrics | |||
RIP software | Wasatch softrip | |||
Additional Drying system | Yes(winds fans+heating) | |||
Feeding system | constant tension high-precision feeding system+ | |||
Take-up system | Auto(with rewinding high-tech air shaft) | |||
Print port | USB2.0 | |||
Temperature | 20-30°C | |||
Recommend Humidity | 40%-70% | |||
printing size | Max to 1.6m |
Product Features
1. High &Stable quality, high speed, high color saturation
2. Improved network system, Printer with 1000MB port to achieve the high-speed transmits.
3. Strong hard mechanical structure, with firm welding technology, decreases the shake during printing, and avoids lowing the printing quality caused by shake.
4. Media tension auto adjustment system
Printer media feeding system with tension sensor, from sensor data information, it can adjust the tension while feeding the fabric, avoid and decrease to make thelines or wrinkle on fabrics caused by high tension during feeding and printing.
5. EPC automatic conrrect feeding control system
Machine equipped with EPC auto correct feeding control system,with infrared sensor and develop shaft, the high-tech system will prevent and correct fabric running in a wrong direction, thus keep the fabric moving more straightly and smoothly, print more accurately.
6. Advanced Auto Rewinding system
Machine with strong auto rewinding system and control panel, qualified with 150D 60in 70Y Rewinding Air shafts parallelism test and load test qualified with 150D 6in 750Y polyester fiber weight test.
7. Patented Rubber roller system
Printer with patented rubber roller technology, keep fabric move more straight than belt type digital printer during printer, improve the printing accuracy.
8. Printer with humanized control panel, it’s very clear for operate. Also install high quality Siemens control panel for controlling the motors.
9. Printer with washing tanks which load the waste inks sprayed the rubber roller during printing, effectively avoid ink spray on fabric while printing.
10. With different models supply optional, To satisfied customer different demands on cost, colors, speed.
11. Machine modified from original Epson sure color model, To guarantee the printing quality and printer stability.
12. Low printing cost.
13. Fast speed than market mostly digital textile printer, not only for sample, but also suitable for bulk production.
Packing:Seaworthy Wooden Case
Leadtime:Within 20 days after we received downpayment
Warranty :
1 year trouble-free warranty. During warranty period, we will send free parts for replacement , while broken parts should be sent back. (not including printhead & Ink Supply System)
Technical Support :
Lifetime online technical support available.
1. After confirmed order details, we will make Proforma Invoice for you.
2. After received your downpayment, will start test machine carefully. Ensure the excellent performance.
3. After tested the machine, will pack and send out.
4. When you received the printer, there is user manual and video to guide you install,operate and maintain.
5. When any technical issues, you can contact with our technician directly. They will help you solve the problem by Skype or Teamviewer. So you can rest assured about the after service.
6. We provide free training in our factory. When order several sets, can also send technician to your place. Help set up machine, and provide training to your staff.
