Plastic Sheet Extrusion Line / pp Sheet Making Line

Plastic Sheet Extrusion Line / pp Sheet Making Line thumbnail-1
Plastic Sheet Extrusion Line / pp Sheet Making Line photo-1
US$ 40,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Sheet
Plastic Processed:
PP
Contact Supplier Request Quote Chat Now
Zhangjiagang Mooge Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Sheet
Plastic Processed PP
Screw Design Single-screw
Automatic Grade Automatic PP sheet making line
Place of Origin Jiangsu, China
Brand Name Mooge PP sheet making line
Model Number MG series PP sheet making line
Voltage 380v/50hz/3ph or as required
Power(W) According to model
Dimension(L*W*H) 20*2.5*2.5m
Weight 20T
Certification CE/ISO
After-sales Service Provided Engineers available to service machinery overseas

Specifications

PP sheet making line
1.Full Automatic Plastic Extruding Machine
2..Low trouble with advanced design

PP sheet making line /PP sheet making machine/  PP Sheet Extruder Machine

Usage of PP sheet making line  :

PP sheet making line  is used to process granular PP/PE/PS/PET into sheet material, through the

processing of heating, extruding and rolling, the sheet to be used of thermoforming machine.



Characteristic- PP sheet making line  :

1.The screw of  PP sheet making line  uses big ratio of length and diameter,its formed effect is nice,the thickness

of the lake board is equal and the running speed is same.

2.The PP sheet making line  use advanced hydraulic pressure high speed net changing fitting without stopping

 the machine,so the operation is convenient,the function is excellent,and it can improve the productive efficiency.

3.The PP sheet making line  can use different plastic to produce the compound flake bord with different colors

according to different products.



Production line configuration reference-  PP sheet making line

1. Vacuum auto Loader + Hopper Dryer

1 set

2. Main single screw extruder

1 set

3. Hydraulic network auto changing system

1 set

4. Mould/Die head

1 set

5. Three-roller Calender

1 set

6. Temperature controller of three rollers

1 set

7. Cooling frame with side cutting unit

1 set

8. Haul off machine

1 set

9. Cutting machine or Winding machine

1 set

10. Stacker

1 set



Technical parameter-   PP sheet making line

Model number Model of Extruder Width of products(mm) Line speed(m/min) Output(kg/h)
Calendering type Casting type
PS PE PP PET PS PE PP PET
MG1000 SJ90/33 850 1.5-15 200 200 150 200 120 150 100 120
MG1200 SJ90/33 1050 1.2-12 200 200 150 200 120 150 100 120
MG1400 SJ120/33 1250 1.5-15 250 250 200 250 150 180 120 150
MG1600 SJ120/33 1450 1.2-12 250 250 200 250 150 180 120 150
MG1800 SJ120/33 1600 1.2-12 280 280 220 280 180 200 150 180


Ø Quality Control-- PP sheet making line  :

  • We have technical, engineer team design the sample machinery before enter into market
  • Production QC team ensure the machine manufacturing quality
  • We will running every machine after finished before shipment
  • Optional choose by client running the machinery by material

Ø Service System--  PP sheet making line  :

  • Pre-sale: we given client the details technician offer, sign the sales contract etc.
  • In-sales: we supply the details layout, installation instruction, technician support for the clients;
  • After sales: we arrange engineer to install the machinery and training the workers for client;
  • We have 24hours team to solve the after sales problem;
  • We have free spare parts with the machine;
  • We supply long term spare parts for every customer
  • We always up date the new technology to every customer

Ø Picture of  PP sheet making line :

plastic sheet extrusion line / pp sheet making lineplastic sheet extrusion line / pp sheet making lineplastic sheet extrusion line / pp sheet making lineplastic sheet extrusion line / pp sheet making lineplastic sheet extrusion line / pp sheet making line
