Specifications:
ETP T1-T5 tinplate coil TFS DR8
1,Thickness:0.14mm-0.60mm
2,Width:600-1020mm
3,Temper Grade:T1-T5
Type: in coil or in sheet
Details:
Thickness |
0.21/0.23 mm as against 0.27/0.28/0.29 mm for Single Reduced OC Tinplate. |
Size |
895 mm x 660 mm, 900 mm x 660 mm, 905 mm x 660 mm for the body and 764 mm x 1015 mm for the top/bottom sizes. |
Temper |
DR-08 |
Yield |
Compared to Single Reduced Tinplate in 0.28 mm, the yield of 15 kg. Container in DR quality of 0.21 mm thickness will increase by 25% to 33% |
Surface Finishes | |||
Code |
Classification |
Roughness Value |
Specific Finishes |
B |
Bright Finish |
0.15 - 0.35 |
A luster surface provided by a flow-brightened tin coating on a smoothly grindstone finished steel base. |
R |
Stone Finish |
0.30 - 0.50 |
A luster surface provided by a flow-brightened tin coating on a steel base characterized by a directional grindstone pattern. |
SSF |
Super Stone Finish |
0.50 - 0.70 |
|
S |
Silver Finish |
0.80 - 1.20 |
A luster surface provided by a flow-brightened tin coating on a coarse dull finish steel base. |
M |
Matte Finish |
0.80 - 1.20 |
A dull surface provided by an unmelted coating generally on dull finished steel base. |
Competitive Advantage:
Low weight and high strength - making tinplate packaging easy to ship and store.
Optimum protection of food products - from impurities, bacteria, moisture, light, and odours.
Unsurpassed safety of tinplate containers for chemical/technical products.
Tinplate is an eco-friendly packaging material offering 100 percent recyclability - any number of times, and without quality loss.
Compared with other materials such as aluminum, tinplate offers significant cost benefit
Material savings through down-gauging. Tinplate is ideally suited for the drawing and wall ironing (DWI) process used in the production of beverage cans. Reductions to just one-third of the original sheet thickness are feasible (special deep-drawing grades).
Direct printing, embossing and new shaping techniques increase the material's marketing potential: tinplate packaging attracts consumer attention and favorably influences purchasing decisions. As a result, it is increasingly used for packaging up-market or trendy items such as watches, perfumes, and mobile telephone cards.
The "shaped can" technology permits the production of cans in a diversity of shapes.
