Specifications
1Model Of Connection:Three-phase Four-wire2Excitation:Brushless AVR
3Rated Power Factor:0.8(Lag)
4Adjustment for Voltage:AV
Data of 6 cylinder Gas Genset for50KW,60KW,75KW,80KW,100KW,120KW
Genset Model |
HF-50GFQ |
HF-60GFQ |
HF-75GFQ |
HF-80GFQ |
HF-100GFQ |
HF-120GFQ |
||||||||||||||||
Model Of Connection |
Three-phase Four-wire |
|||||||||||||||||||||
Excitation |
Brushless AVR |
|||||||||||||||||||||
|
Rated Power (kw) |
50 |
60 |
75 |
80 |
100 |
120 |
||||||||||||||||
|
Rated Current (A) |
90 |
108 |
135 |
144 |
180 |
216 |
||||||||||||||||
|
Rated Voltage (V) |
400 |
|||||||||||||||||||||
|
Rated Frequency (HZ) |
50 |
|||||||||||||||||||||
Rated Power Factor |
0.8(Lag) |
|||||||||||||||||||||
|
Adjustment For Voltage |
AVR(Automatic Control) |
|||||||||||||||||||||
ENGINES |
Model |
HF6105Q |
6105ZQ |
6140Q1 |
6140Q1 |
6140Q2 |
6140Q3 |
|||||||||||||||
Type |
In line, 4-Stroke, Water Cooled, Electronic Control Ignition |
|||||||||||||||||||||
|
Cylinder No *Bore*Stroke (mm) |
6× 105×125 |
6× 105×125 |
6× 140×160 |
6× 140×160 |
6× 140×160 |
6× 140×160 |
||||||||||||||||
|
Displacement (L) |
6.5 |
7.5 |
14.8 |
14.8 |
14.8 |
14.8 |
||||||||||||||||
Compression Ratio |
11.5:1 |
|||||||||||||||||||||
Rated Power |
60 |
71 |
85 |
90 |
110 |
132 |
||||||||||||||||
Rated Speed |
1500 |
|||||||||||||||||||||
Speed Control Type |
Electronic Speed Control |
|||||||||||||||||||||
Starting Method |
Electric Start |
|||||||||||||||||||||
|
Consumption (m³/kwh) |
0.30(Natural gas) 0.50(Biogas) |
|||||||||||||||||||||
|
Dimension L*W*H(mm) |
2100×780 ×1300 |
2200×800 ×1400 |
2650×900 ×1650 |
2650×980 ×1800 |
2650×1100 ×1900 |
2650×1100 ×1900 |
||||||||||||||||
Net Weight (kg) |
1650 |
1800 |
2000 |
2100 |
2450 |
2600 |
||||||||||||||||
