Home > Products > rebar coupler > Langrui Brand Rebar Coupler with High Quality
Langrui Brand Rebar Coupler with High Quality
- 300000 Piece / Pieces per Month
- Tianjin
- T/T Credit Card
Product Details
Place of Origin: | Hebei, China | Brand Name: | Langrui | Model Number: | LR-RC-417 |
Material: | Steel |
Product Description
Langrui Steel Rebar Coupler for Building with High Quality |
Name | Value |
Brand | Langrui |
Model | LR-RC-417 |
Thread Pitch | 2.5mm,3.0mm,3.5mm |
Thread Angle | 75° |
Material | 45# High-quality Carbon Steel |
Out diameter | 14 mm--40mm |
Length | 35mm--120mm |
Place of Origin | China(mainland) |
Material: 45# high-quality carbon structural steel
Specification:14mm – 40mm
Use: Apply to HRB335, HRB400 reinforced the connection
Performance: With the reinforced mechanical connection technology common point of
orderJGJ107 – 2003 level joint performance requirements.
Type | Thread Pitch | Length | OD | INNER DIAMETER |
D14 | 2.5P | 40mm | 22mm | 12.28 (0~+0.20) |
D16 | 2.5P | 45mm | 25mm | 14.28 (0~+0.20) |
D18 | 2.5P | 50mm | 27mm | 16. (+0.10~+0.30) |
D20 | 2.5P | 55mm | 30mm | 18 .(+0.1~+0.30) |
D22 | 2.5P | 60mm | 32mm | 20 (+0.1~+0.30) |
D25 | 3.0P | 65mm | 38mm | 23 (+0.15~+0.35) |
D28 | 3.0P | 70mm | 42mm | 26 (+0.15~+0.35) |
D32 | 3.0P | 75mm | 48mm | 29.8 (0~+0.20) |
D36 | 3.0P | 85mm | 53mm | 33.8 (0~+0.20) |
D40 | 3.0P | 90mm | 58mm | 37.5 (0~+0.20) |
Korean Standard:
Material: 45C Cold Draw Pipe
Technical Standard: Yield Strength 500N/mm2, Tensile Strength 640N/mm2
Type | Thread Pitch | Length | OD | INNER DIAMETER |
D13 | M13*1.5P | 30mm | 19mm | 11.7-11.8 |
D16 | M16*2.0P | 38mm | 23mm | 14.2-14.3 |
D19 | M20*2.5P | 45mm | 28mm | 17.7-17.8 |
D22 | M23*2.5P | 50mm | 33mm | 20.7-20.8 |
D25 | M25.5*3.0P | 58mm | 38mm | 23.2-23.3 |
D29 | M29.5*3.5P | 65mm | 43mm | 26.2-26.3 |
D32 | M33*3.5P | 70mm | 48mm | 29.7-29.8 |
D35 | M36*4.0P | 75mm | 53mm | 32.2-32.3 |
D38 | M39*4.0P | 80mm | 56mm | 35.2-35.3 |
D41 | M42*4.0P | 100mm | 60mm | 38.2-38.3 |
1) Material: carbon steel
2) Can be used to joint rebar with diameter 12mm to 40mm
3) Straight thread inside the adapter sleeve
4) High intension of tie-in and 100% exerted grade reinforce steel bar
connection technology guideline
5) Power adaptability may fully meet varies inquires of steel bar reinforcing
technology
6) Not limited to climate, whole day construct insures time limit for a project
7) Stable quality, can be measured and eyeballed at any time
8) When connected, only use cannulation and spanner, don't use any energy
source and Equipment, safe construct
9) No pollution
10) Economize energy source and material
Test result: broken bar:
Application |
Steel Machanical Construction Rebar Splicing Coupler used to rebar
mechanical splicing.
1. Steel rebar splicing coupler type:Paralleled type,left hand type,right hand
type,right hand left hand type and reducing type.
2.Range of application:Suitable for rebar of HRB335 and HRB400.Diameter
from 14mm to 40mm.
Production Process |
packing inspection |
The rebar sleeves are packed with nilon bag.Couplers are not easy to rust.
Contact me |
Contact Us
- Hebei Langrui Environmental Engineering Co., Ltd.
- Contact nameNancy Zheng
- Phone0086-312-6921360
- AddressNo. 1, Xingyuan Road, Dingxing County
