High frequency welding heat pipe fins tube

Specifications

High frequency welding heat pipe fins tube
1.Application : boiler economizer
2.Material : carbon steel-aluminium
3.MOQ:500m

1.  High frequency welding heat pipe fins tube

2. Production range

    Bare pipe (OD):25mm-165mm

    Bare pipe length (L):1-12m

    Fin spacing (t):5-30mm

    Fin thick (Sn):0.6-3.0mm

    Fin height (hf): general no more than the radius of bare pipe(5-30mm)

3. High technology, Boiler economizer air exchanger new air heater ,heat transfer area is 8 times than the light tube, extruded heat exchanger parts, lower cost, reasonable price, much more advanced than the other heat exchangers finned tube.

4. Our main products is single/bimetallic metal fin tube for heaters with carbon steel/stainless steel/copper/aluminum welded fin, and the type of tubes are welded or seamless.

5. Different kinds of Boiler economizer air exchanger new air heater can be developed and designed according to your requirements, finning type including High frequency welding / Extruded / L-foot / H type / Embedded etc.

6. Weld able material: carbon steel, corrosion resistant steel, stainless steel, alloy steel and aluminum&copper etc.

7. Applied range of the carbon fin / stainless steel fin tube products: Bolier economizer/ Power plant waste bolier/Petrochemical engineering and varioue types pof heat exchangers.

8. Top quality, competitive price, fast delivery, excellent service



MORE ENERGY-EFFICIENT AND ENVIRONMENTAL!

WE ARE TRUST WORTHY! WAITING FOR YOUR EARLY REPLY!





Tube Detail	Material	Carbon Steel(20#,3087,Q235),Alloy Steel,Stainless Steel(304,316L), Copper Pipe
	OD	≥16mm
	THK	2-8mm
	Long	0-12m or as request
Fin Detail	Material	1060, 6063.
	High	5-30mm, less than the radius of the base tube.
	OD	20-70mm.
	Pitch	0-8mm, generally 2.5-5.0mm.
	Thk	0.35-0.5mm.
Application	Air cooling unit ,Product coolers - gas, Heat exchangers ,chemicals, petrochemicals, oil etc.





Real product show





The machine is working



Package:





Contact person:
