Help CenterQC11Y 25x3200 Hydraulic Guillotine Shearing Machine
Related Products
-
Multifunction Aluminium Embossing Machine for SaleUS$ 26,000 - 32,000MOQ: 1 Set -
Electric Embossing Machine for SaleUS$ 26,000 - 32,000MOQ: 1 Set
-
Small Automatic Aluminum Plate Embossing MachineUS$ 26,000 - 32,000MOQ: 1 Set
-
Hot Sale Aluminum Plate Embossing MachineUS$ 26,000 - 32,000MOQ: 1 Set
-
QC11Y 12X2500 Hydraulic Guillotine Shearing MachineUS$ 1 - 2MOQ: 1 Set
Specifications
Shearing machine is more widely used in cut all kinds of metal sheet plates in different thicknessQC11Y 25x3200 Hydraulic Guillotine Shearing Machine
Shearing machine is more widely used in machining a cut hydraulic pendulum shearing cutting equipment, it can cut all kinds of the steel plate with different thickness.Steel plate welded construction,hydraulic drive,nitrogen cylinder return.Convenient to operate,beautiful appearance and more stable performance.There’s instruction book for the blade gap adjustment to make the adjustment more quick and convenient.Support the lighting device and the adjustment of travel volume of the up shaft to any extent. Working area has the fence type person safety protection devices. Digital display device of both back gauge size and cutting times.
Specification |
Unit |
QC11Y 25X3200 |
|
Max thickness of cutting plate |
mm |
25 |
|
Max width of cutting plate |
mm |
3200 |
|
Cutting angle |
° |
30’-3.5° |
|
Number of stroke |
min-1 |
5-15 |
|
Range of backgauge |
mm |
20-800 |
|
Backgauge Rang |
mm |
800 |
|
Main motor |
kw |
37 |
|
Overall Size(L*W*H) |
mm |
3980x2650x2800 |
|
Weight |
KG |
24,000 |
Main parts of machine
1.Main electric elements:Siemens;
2.Hydraulic valves: Jining Taifeng, OMG ;
3. Oil pump: Shanghai Chengjie
4. Seal rings:VALQUA from Japan
Certificates:
