Specifications
NEW!!! CREE XPL led, CREE XP-L leds, Highest Efficacy Single-Die LED
Size: 3.45 x 3.45mm
NEW!!! CREE XPL led, CREE XP-L leds, Highest Efficacy Single-Die LED
Highest Efficacy Single-Die LED
The XLamp® XP-L LED is the first commercially available single-die LED to deliver breakthrough efficacy of up to 200 lm/w at 350 mA. The game-changing Cree® XLamp XP-L LED delivers an immediate performance increase of 50% or more as a drop-in upgrade for lighting designs based on Cree’s market-leading XLamp XP-G LEDs. As the brightest member of the industry’s only family of high-density-class discrete LEDs, the new XP-L LED redefines system performance, cost and size of LED lighting.
| Size (mm x mm) | 3.45 x 3.45 |
| Maximum drive current (A) | 3 |
| Maximum power (W) | 10 |
| Light output - White | Up to 1079 lm @ 10 W, 85°C |
| Typical forward voltage @ 0.35 A (V) - White | 2.95 |
| Viewing angle (degrees) - White | 125 |
| Binning - White | 85°C, ANSI |
| Thermal resistance (°C/W) - White | 2.5 |
| Reflow-solderable | Yes – JEDEC J-STD-020C-compatible |
| RoHS and REACH-compliant | Yes |
Notes:
• Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and ±2
on CRI measurements.
• Typical CRI for Cool White (5000 K – 8300 K CCT) is 65.
• Typical CRI for Neutral White (3700 K – 5000 K CCT) is 75.
• Typical CRI for Warm White (2600 K – 3700 K CCT) is 80.
• Minimum CRI for 70-CRI White is 70. • Minimum CRI for 80-CRI White is 80.
• Minimum CRI for 85-CRI White is 85. • Minimum CRI for 90-CRI White is 90
* Flux values @ 25 °C are calculated and are for reference only.
** Calculated flux values at 1500 mA, 2000 mA and 3000 mA are for reference only.
Applications:
Directional
Low- & High-Bay
Roadway & Parking
High-End Portable
