New Type Dust Colllector Wide Sold In India20 Years manufacturing and design experience
OEM ODM welcome
New Type Dust Colllector Wide Sold In India
Export country of dust collector:
Russia,India, Vietnam, Kazakhstan, Mongolia, Pakistan, Iran, Ecuador, middle east, Oceania, Europe , America and other countries and areas.
Application of Dust Collector
It is widely used to collect dust in grinder, crusher, packing machine, silo top, matching materials of cement industry. It can clean not only air with common dust, but air withhigh density (even 1300g/Nm3), so it can collect final product of vertical mill and 0-sepa separator. It can be also widely used in grain, light industry, electric power, chemical industry, metallurgy, etc.
Working Principle of dust collector:
1. The dust-laden air enters the bag filter.
2. The dust /powder separates inside the bag filter chamber.
3. The air is uniformly distributed avoiding channeling while the powder is separated.
4. Initially a coat of material forms on the bags. Subsequently,the coat acts as the filtering medium.
5. The dust is accumulated on filter elements while the air passes through the filter bags from outside to inside.
6. The accumulated powder is dislodged from the bags by reverse pulsejet air intermittently.
7. The dislodged powder falls on bottom cone and is discharged through powder discharge valves.
8. The dust free air is sucked by induced draft fan and is exhausted to atmosphere.
Main Feature of Dust Collector
1. By use of impulse technology, the dust collector has a strong ability of cleaning dust, high efficiency, and is with low leakage rate, less energy and steel consumption, small areas. The equipment works stably, and wins good economic returns, which is applied for cleaning dust in several industries, such as metallurgy, building materials, machine, chemistry, electricity, light industries and so on.
2. The box is designed in a good seal. Excellent seal materials are used in making the inspected door. During its process, check it by using diesel and with low leakage.
3. At the opening of outlet is with compact layout and low resistance.
4. Adopt blowing pulse cleaning dust so as to make the cycle extended and the energy reduced. It can improve twice service life of filtering bags and valves.
5. Change the filtering bags without stopping the machine and overhaul has no effect on operating the equipments.
6. By putting bags on the upper part, checking level is improved.
| Type | MC24-II | MC36-II | MC48-II | MC56-II | MC60-II | MC72-II | MC84-II | MC96-II | MC108-II | MC120-II |
|
Filter area
|
19.3 | 29 | 38.6 | 45.1 | 48.3 | 57.9 | 67.6 | 77.2 | 86.9 | 96.6 |
| m² | ||||||||||
| Number of filter bag | 24 | 36 | 48 | 56 | 60 | 72 | 84 | 96 | 108 | 120 |
| Number of pulse valve | 4 | 6 | 8 | 7 | 10 | 12 | 14 | 16 | 18 | 20 |
| Filtering capacity | 2316- | 3480- | 4632- | 5412- | 5796- | 6948- | 8112- | 9264- | 10428- | 11592- |
| m³/h | 4632 | 6960 | 9264 | 10824 | 11592 | 13896 | 6224 | 18528 | 20856 | 23184 |
|
Size of filter bag
|
Φ130×2000 | |||||||||
| mm | ||||||||||
| Size | 1025×1678 ×3676 | 1425×1678 ×3676 | 1823×1678 ×3676 | 2010×1678 ×3676 | 2225×1678 ×3676 | 2625×1678 ×3670 | 3075×1678 ×3676 | 3949×1678 ×3676 | 4140×1678 ×3676 | 4389×1678 ×3676 |
| lengthxwidthxheight | ||||||||||
| mm | ||||||||||
| Efficiency% | 99-99.6 | |||||||||
|
Obstruction
|
120-150 | |||||||||
| mmH2O | ||||||||||
| Filtering velosity | 2-4 | |||||||||
| m/min | ||||||||||
| Inlet dust concentration | <15 | |||||||||
| g/m³ | ||||||||||
| Air pressure | 4 | |||||||||
| kg/cm2 | ||||||||||
| Air consumption | 0.08-0.34 | 0.13-0.5 | 0.17-0.67 | 0.19-0.76 | 0.21-0.84 | 0.25-1.01 | 0.3-1.18 | 0.34-1.34 | 0.38-1.46 | 0.42-1.68 |
| m³/min | ||||||||||
| Weight | 1133 | 1485 | 1496 | 1632 | 1730 | 1950 | 2230 | 2400 | 2698 | 2870 |
| kg | ||||||||||
Model |
SLDM168-5 |
SLDM168-6 |
SLDM168-7 |
SLDM168-8 |
SLDM168-9 |
SLDM168-2*5 |
SLDM168-2*6 |
SLDM168-2*7 |
SLDM168-2*8 |
SLDM168-2*9 |
|
|
Air volume (m3/h) |
9.6~12.0 |
11.52~14.4 |
13.44~16.8 |
15.36~19.2 |
17.28~21.6 |
19.2~24.0 |
23.04~28.8 |
26.88~33.6 |
30.72~38.4 |
34.56~43.2 |
|
Total filter area(m2) |
2000 |
2400 |
2800 |
3200 |
3600 |
4000 |
4800 |
5600 |
6400 |
7200 |
|
G.W. (t) |
50 |
60 |
70 |
80 |
90 |
100 |
120 |
140 |
160 |
180 |
|
Chamber |
5 |
6 |
7 |
8 |
9 |
10 |
12 |
14 |
16 |
18 |
|
Filter bag |
Qty. |
840
|
1008
|
1176
|
1344
|
1512
|
1680
|
2016
|
2352
|
2688
|
3024
|
Specification |
130(D. meter)×6000 |
||||||||||
Pulse valve |
Qty. |
60 |
72 |
84 |
96 |
108 |
120 |
144 |
168 |
192 |
216 |
Specification |
3″ |
||||||||||
|
Resistance (Pa) |
1200~1600 |
||||||||||
Air consumption(m3/min) |
2~4 |
||||||||||
Discharge Density(mg/N m3) |
less than 50 |
||||||||||
Air leakage (%) |
less than 3 |
||||||||||
Pressure |
0.2~0.4 |
||||||||||
Note: this parameters just for reference and we also have other models .if you are interested in this equipment,please do feel free to contact me, I will reply you the details ASAP.
Dust Collector From Xingbang
Henan Xingbang is a professional dust collector supplier in China and is the production and export base of dust collector China.
Processional Research and Development team; Strict quality control;
Provide complete service equipment installation, testing ,maintenance and staff training.
