Industrial Dust Collector for High Concentrated GasGood deashing effect .
Low resistance of the main body
Industrial Dust Collector for High Concentrated Gas
Description of pulse bag dust collector:
Dust Collector is a kind of highly efficient collector which is designed on the base of overseas advanced technology. It combines advantage of locellus blowback dust collector and jetting pulse cleaning dust collector, avoids less strength of locellus blowback and simultaneous re-absorbing of jetting pulse cleaning dust and filter. It adopts highly efficient off-line method, so it can clean dust with larger capacity, higher efficiency, lower system resistance, longer life of filter-bag, etc.
Features:
1.Clean dust with offline pulse and effectiveness is up to 99.9%.The dust has no secodary absorption.It is specially used for handling high concentrated gas.
2.Use reverse blowing in high temperature to prevent condensation effectively.
3.Use new materials for cleaning dust and the machine is with reliable tracking system of gas temperature.I t can adapt to various conditions.
4.Automatic control by computer,the machine is easy to be operated with good reliability.
5.The dust collector is with air box,which avoids partial damage and inconvenient installation.
| Type | MC24-II | MC36-II | MC48-II | MC56-II | MC60-II | MC72-II | MC84-II | MC96-II | MC108-II | MC120-II |
|
Filter area
|
19.3 | 29 | 38.6 | 45.1 | 48.3 | 57.9 | 67.6 | 77.2 | 86.9 | 96.6 |
| m² | ||||||||||
| Number of filter bag | 24 | 36 | 48 | 56 | 60 | 72 | 84 | 96 | 108 | 120 |
| Number of pulse valve | 4 | 6 | 8 | 7 | 10 | 12 | 14 | 16 | 18 | 20 |
| Filtering capacity | 2316- | 3480- | 4632- | 5412- | 5796- | 6948- | 8112- | 9264- | 10428- | 11592- |
| m³/h | 4632 | 6960 | 9264 | 10824 | 11592 | 13896 | 6224 | 18528 | 20856 | 23184 |
|
Size of filter bag
|
Φ130×2000 | |||||||||
| mm | ||||||||||
| Size | 1025×1678 ×3676 | 1425×1678 ×3676 | 1823×1678 ×3676 | 2010×1678 ×3676 | 2225×1678 ×3676 | 2625×1678 ×3670 | 3075×1678 ×3676 | 3949×1678 ×3676 | 4140×1678 ×3676 | 4389×1678 ×3676 |
| lengthxwidthxheight | ||||||||||
| mm | ||||||||||
| Efficiency% | 99-99.6 | |||||||||
|
Obstruction
|
120-150 | |||||||||
| mmH2O | ||||||||||
| Filtering velosity | 2-4 | |||||||||
| m/min | ||||||||||
| Inlet dust concentration | <15 | |||||||||
| g/m³ | ||||||||||
| Air pressure | 4 | |||||||||
| kg/cm2 | ||||||||||
| Air consumption | 0.08-0.34 | 0.13-0.5 | 0.17-0.67 | 0.19-0.76 | 0.21-0.84 | 0.25-1.01 | 0.3-1.18 | 0.34-1.34 | 0.38-1.46 | 0.42-1.68 |
| m³/min | ||||||||||
| Weight | 1133 | 1485 | 1496 | 1632 | 1730 | 1950 | 2230 | 2400 | 2698 | 2870 |
| kg | ||||||||||
Model |
SLDM168-5 |
SLDM168-6 |
SLDM168-7 |
SLDM168-8 |
SLDM168-9 |
SLDM168-2*5 |
SLDM168-2*6 |
SLDM168-2*7 |
SLDM168-2*8 |
SLDM168-2*9 |
|
|
Air volume (m3/h) |
9.6~12.0 |
11.52~14.4 |
13.44~16.8 |
15.36~19.2 |
17.28~21.6 |
19.2~24.0 |
23.04~28.8 |
26.88~33.6 |
30.72~38.4 |
34.56~43.2 |
|
Total filter area(m2) |
2000 |
2400 |
2800 |
3200 |
3600 |
4000 |
4800 |
5600 |
6400 |
7200 |
|
G.W. (t) |
50 |
60 |
70 |
80 |
90 |
100 |
120 |
140 |
160 |
180 |
|
Chamber |
5 |
6 |
7 |
8 |
9 |
10 |
12 |
14 |
16 |
18 |
|
Filter bag |
Qty. |
840
|
1008
|
1176
|
1344
|
1512
|
1680
|
2016
|
2352
|
2688
|
3024
|
Specification |
130(D. meter)×6000 |
||||||||||
Pulse valve |
Qty. |
60 |
72 |
84 |
96 |
108 |
120 |
144 |
168 |
192 |
216 |
Specification |
3″ |
||||||||||
|
Resistance (Pa) |
1200~1600 |
||||||||||
Air consumption(m3/min) |
2~4 |
||||||||||
Discharge Density(mg/N m3) |
less than 50 |
||||||||||
Air leakage (%) |
less than 3 |
||||||||||
Pressure |
0.2~0.4 |
||||||||||
Note: this parameters just for reference and we also have other models .if you are interested in this equipment,please do feel free to contact me, I will reply you the details ASAP.
Skype: lorraine72521
E-mail: lorraine at
M.P.: 0086-13526814225(lorraine Li)
Welcome your inquiry ! If you are interested in our equipments , please do not hesitate to contact me, I'm lorraine . I will reply you the details ASAP.
