Good Price Jigger Used in Mine Beneficiation Plant |
Henan XBM specialize in manufacture gold mining machine, 20 years experiences, professional design, first-class quality, sales lead !
We offer spare parts for free for the top five customers every month!!!
1.Introduction of |
Jiggers are a kind of energy saving gravity equipment development and improved on the basis of traditional jigs according to the the oretic layering law of jig beds. Their jigging pulsation curves take the shape of sawtooth waveform which gets the ascending water to travel more rapidly than the descending water.
2.Parameters of |
| Type | Specif ication | Jigger chambers cross section | Jigger chambers | Stroke coeffi cient | Diagram | Max feeding size (mm) | Capa city (t/h) | Water consum ption (t/h) | Motor power (kw) | Weight (t) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
L×W (mm) | Unit area(m²) | columns Nos. | Chamber Nos. | Total area (m² ) | Strokes (mm) | Stroke frequency (r/min) | |||||||||
| Lateral Drive | LTP- 34/2 | Square | 450 ×300 | 0.135 | Single | 2 | 0.27 | 0.58 | 0-25 | 320-420 | 12 | 2-6 | 4-10 | 1.1 | 0.75 |
| Bottom driven | LTA- 55/2 | Square | 500 ×500 | 0.25 | Single | 2 | 0.5 | 0.5 | 0-26 | 250-350 | 5 | 1-5 | 4-20 | 1.1 | 0.60 |
| LTA- 100/2 | Square | 1000 ×1000 | 1.0 | Single | 2 | 2.0 | 0.5 | 0-26 | 250-350 | 5 | 1-25 | 20-60 | 2.2 | 1.56 | |
Side drive | LTC- 69/2 | Square | 900 ×600 | 0.54 | Single | 2 | 1.08 | 0.56 | 0-50 | 220-350 | 12 | 6-9 | 40-60 | 1.5 | 1.42 |
| 2LTC- 79/4 | Square | 900 ×700 | 0.63 | Single | 4 | 2.52 | 0.48 | 0-50 | 160-250 | 12 | 5-15 | 20-90 | 2.2 | 2.45 | |
| 2LTC-912/4 | Square | 1200 ×900 | 108 | Single | 4 | 4.32 | 0.49 | 0-50 | 160-300 | 12 | 7-25 | 60-120 | 3 | 3.50 | |
| 2LTC-366/8T | Square | 600 ×(300-600) | 0.2-0.34 | Single | 8 | 2.16 | 0.58-0.40 | 0-50 | 120-300 | 5 | 3-6 | 20-40 | 1.1×2 | 1.60 | |
| 2LTC-6109/8T | Square | 500 ×(600-100) | 0.58-0.86 | Single | 8 | 5.76 | 0.52-0.35 | 0-50 | 120-300 | 5 | 10-20 | 80-120 | 2.2×2 | 4.65 | |
3.Features of |
1. High capacity
2. High concentration ratio and high recovery
3. Fabricated with highest quality material
4. Easy to install, operate and maintain
5. The pulsation curve is saw-tooth wave shape facilitate heavy mineral to settling
6. Saving water 30-40% than ordinary jigger
7. The pulsation speed very easy adjusted by regulator
8. Suitable for roughing and desliming
Gold Mining Jigger Machine
4.Structures of |
5.Advantages of |
Jigger has advantages as follows: stepless speed regulation; the machine vibrates evenly and the minerals can be processed uniformly; it has remarkable adaptability and is especially good at handling medium and fine minerals; low water consumption; low maintenance.
6.Application of |
Jigging machine is widely used in gravity concentration of tin, tungsten, placer gold, hematite ore, manganese, titanium, antimony, lead, tantalum, niobium and other minerals.
Personalized reception: Offer the full and personalized service in the whole journey after you come to China.
Lifetime Technical Support: Offer one year of free equipment warranty and lifetime technical support.
Monitor Production Progress: You can monitor production progress personally any time after confirming the order.
Product Delivery: We have developed a long and good relationship with many shipping agents, such as APL, MSK, CSCL, MSC, etc.
Installation and Training: Send technicians to the client site for guiding the installation and adjustment, and training operators to complete the inspection and acceptance together with you.
Henan Xingbang Heavy Machinery Co., Ltd.(XBM) is a largescale enterprise with Integration of researching, development, manufacturing and marketing mining machinery. Our main business scope is: stone crushing series, industrial grinding series, ore dressing equipment and cement equipment.
Our products have been exported to a number of foreign countries, including southeastern Asia, South Africa, South America etc. And numerous customers have come to visit our factories with the purpose of choosing their ideal machine. China XBM always bears in mind the aim "Quality First; Honesty Foremost"!
Over 20 years experiences in this field; Exported to more than 30 countries in Africa, Asia, America; Processional Research and Development team; Strict quality control; Provide complete service equipment installation, testing ,maintenance and staff training.....
All XBM people sincerely welcome customers all over the world to visit our factory and on-the-spot investigation !
Looking forward to cooperating with you !
