China Spring Cone Crusher

FOB Price

US$ 50,000 - 160,000 / Set

1 Set(Min. Order)

Port Qingdao/Shanghai/ Tianjin
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Cone Crusher
Application	Stone,sand,limestone,granite,basalt, gold ore, granite, basalt crushing	Motor Type	AC Motor
Power(W)	155kw	Capacity(t/h)	280-480t/h
Place of Origin	Henan, China	Brand Name	XBM
Model Number	PYB1750	Dimension(LWH)	391028943809
Weight	50300kg	Certification	ISO, CE
Warranty	12months	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

China leading spring crusher, XBM cone crusher

cone crusher introduction

Hydraulic cone crusher and spring cone crusher is suitable to crush all kinds of ores and rocks with medium hardness and above. It has features of reliable structure, high efficiency, high capacity, low operating cost, easy adjustment, economical to use and so on. Spring system plays the role of overload protection, which will enable the exotic materials or steel piece to pass through the crushing chamber without any damage to the machine. It adopts grease seal to isolate dust and lubricants, therefore ensure its reliable operation. According to customer demand, respectively, using standard type, medium type and short head type for coarse crushing, medium crushing and fine crushing operation.

cone crusher features

1.Strong crushing force; High efficiency; High crushing capacity.

2.Low operation and maintenance cost, easy to adjust.

3.As spare parts selection and structural design is reasonable, the lifespan will be longer.

4.Reducing downtime.

5.Different types of crushing chambers to satisfy different customers’ requirement.

cone crusher specifications and technical dada

Type	Dia. of Cone (mm)	Adjusting Range of Discharge Opening (mm)	Max Feed Size (mm)	Capacity (t/h)	Motor Power (kw)	Weight (t)	Overall Dimension (mm)
PYB-600	600	12-25	65	15-25	30	5.5	1740×1225×1940
PYD-600	600	3-13	36	5-23	30	5.5	1740×1225×1940
PYB-900	900	15-50	115	50-90	55	10.18	1990×1640×2380
PYZ-900		5-20	60	20-65	55	10.19	1990×1640×2380
PYD-900		3-13	40	15-50	55	10.27	1990×1640×2380
PYB-1200	1200	20-50	145	110-200	110	24.7	2805×2300×2980
PYZ-1200		8-26	100	50-150	110	25	2805×2300×2980
PYD-1200		3-15	50	18-105	110	25.6	2805×2300×2980
PYB-1750	1750	25-60	215	280-480	155-160	50.6	3610×2950×4185
PYZ-1750		10-30	185	115-320	155-160	51	3610×2950×4185
PYD-1750		5-15	85	75-230	155-160	50.5	3610×2950×4185
PYB-2200	2200	30-60	300	590-1000	260-280	84	4790×3430×5080
PYZ-2200		10-30	235	200-580	260-280	85	4790×3430×5080
PYD-2200		5-16	110	120-370	260-280	85	4790×3430×4852

Hydraulic cone crusher and mobile crusher
