15micron Nylon66 filter mesh,high precision of filtration,medical filtering

15micron Nylon66 filter mesh,high precision of filtration,medical filtering

Product Description

 Medical filtering

• Technical parameters



  Item	NO	JPP189
  material		Nylon66 Monofilament
  mesh count	Mesh/cm Mesh/inch	189
  		480
  yarn diameter	micron	43
  mesh opening	micron	15
  thickness	micron	80
  weight	gsm	60
  open area	%	7
  width	m	1.27/1.35



• Features

1.Even hole size,high precision of filtration

2.Smooth filament, immersion resistance,no material drop off

3.Stable chemical and physical properties

4.Widely used in liquid filtration,especially in making tea and coffe bags

• Certificates

1.Standard of quality:ISO9001:2008

2.Food approved:FDA,EC,NO SILLICON

3.Environmental certificate:ROHS

4.Material safety:MSDS,SVHC

5.Raw material test:PA66 MATERIAL TEST REPORT

• Finishing process

HTHP ultrasonic cleanling,high tempreture stabilized finish,unti-infiltration water treatment in 10000-grade purification workshop.

• Testing

a. Thread measuring

selecting the most suitable fibers for intended application

b. Check the mesh count

measuring the mesh count by pick glass

c. Check the mesh opening

measuring the mesh opening & thread diameter by microscope

d. One splice marked with red thread

• Package

Each roll packed in plastic bags,then in weaving bag or carton or woden case.It also can be customized

• Service

1.Heat cutting

2.Laser cutting

3.Ultrasonic welding

4.Raising

5.Calendaring

• Manufacturing process

•
