artificial stone roll for waste paper pulp machine
Bottom Press Roll
Specifications:
1.Used in press section
2.Cast iron roll
3.Roll body coated rubber
Main Technical Parameters:
1. Diameter——650mm
2. Face width——2400mm
3. Roll type——Blind hole roll
4. Roll body material——High strength cast iron HT300
5. Shaft head——45# steel conditioning shaft head
6. Roll surface coated rubber——Hardness“A”95°±2°, thickness 20mm
7. Bearing assembly——113536
8. Lubrication type——Grease lubrication
9. Dynamic balance level——G1.6
10. Equipped with drive out shaft
Suction Press Roll
Specifications
•Suction Return Roll
•Suction Pick-up Roll
•Suction Couch Roll
•Blind Drill Roll
•Guide Roll Press Top roll rubber
Rollers for paper machine
Wire section |
Breast roll, Forwarding Roll, Guide Roll |
Press section |
Blind drill press roll, Plain press roll, Grooved roll, Stonite roll, Felt guide roll, Expander roll |
Dryer section |
guide roll for drying screen or wide felt, pick-up roll |
Others |
calender roll, bow roll, spool, couch roll, back roll, |
Max.capacity |
Dia.1500mm, face length 8000mm |
All rolls are dynamic balanced. | |
After special processing technology journal advantages:
•Enhance hardness of shaft.
•Increase contant area with bearing.
•Extend bearing life time.
Packaging & Shipping
Our products are packaged by wooden or steel box, the main characteristics of the products and which way our customs required will be the factor that we think about when we choose the way to package. Following are more details.
