Help CenterDK 7740 Top Quality CNC Middle Speed Edm Wire Machines for Sale
Related Products
-
DK7132 High Quality Middle Speed Cnc Edm Wire Cutting MachineNegotiableMOQ: 1 Set -
Self-Manufacturing Hot Sale DK7740 Middle Speed EDM Wire Cutting MachineNegotiableMOQ: 1 Set
-
Cnc Middle Speed Wire Cut EDM MachineUS$ 5,000 - 6,000MOQ: 1 Set
-
Brand New Middle Speed CNC Wire Cut EDM With Low PriceNegotiableMOQ: 1 Set
-
2015 Hot Sale Middle Speed Wire Cut EDM With Low PriceNegotiableMOQ: 1 Set
Product features
1.High-performance pulse power supply with mufti-level two-range amplifier, applicable to thick jobs, the thickest being≥800mm.
2.Stable, efficient,lowloss pulse power supply, the maximum cutting efficiency being 120mm/min and
the molybdenum wire loss rate≤0.01/80000mm.
3.Backlash compensation:3B language direct compensation, ranging from 0-9999, as well as backlash compensation with the angle-clearing function, the all-angle rotation function, the translation function,the command reverse function, the command
reverse function and the proportionate scaling function.
4.The fuse protection function, the automatic centralizing and edge-tracing processing and the alarm upon finished job functions.
5.Industrial personal computer-controlled pulse power supply, vertical case, color interface,capable of automatic editing,ISO codes
compatible with 3B,4B languages with simultaneous programming, color 3D figures and real-time cutting sample pictures on display.
6. Standard configure RS-232C interface, workable with Internet accession.
7. Optional hard disk installation and windows desktop, multiple choices for the customer.
cnc wire cut edm dk series
1.Large travel.
2.Four axes independent UV work.
3.Work pieces to 600mm thick.
4.Taper angles up to ± 30°.
5.Standard model is equipped with ± 3° taper attachment.
6.Molybdenum wire diameter 0.12~0.22 mm (down to 0 .08mm).
7.Accuracy: 0.015mm, even 0.01mm.
8.Roughness: Ra 1.6-2.5 µm.
9.Low consumption, material saving.
10.Closed loop glass scales on all four axes for positional accuracy of 0.005mm.
11.Advanced CAD/CAM software with file transfer and translation capabilities.
12.High cutting speed modular is optional.
Products specifictions
Type |
DK7740 |
Worktable Size |
410*710 |
Worktable Travel |
400*500 |
Max. Cutting Sped |
100 |
The Largest Storage Wire Length |
320 |
Max. Work piece Height |
400 |
Wire Electrode Diameter |
Φ0.12~ΦΦ0.18 |
Precision (Cutting the Octagon) |
0.015 |
Taper(Optional) (mm) |
6°~60°/80 |
|
Max. Work piece Weight(kg)
|
450 |
Machine Weight |
1600 |
Machine Dimension |
1870*1350*1800 |
Power Consumption |
AC380ν/220ν50HZ≤2KW |
