Insulation Roofing Building Material Roma Style

Specifications

Long service life,Colorfast,Loading bearing,Light weight,Fire resistance,Water resistance,Anti corrosion,Impact resistance

Advantage



1 Fast Color

The top layer material of JL roof tile is PMMA material, super weather resistance material made by ATOGLAS company is suitable for outdoor use. Our JL roof tile is endowed with super weather ability and able to maintain the color stability even exposing under the condition of ultra-violet radiation, humidity, heat, chillness and impact.

Our JL roof tile has passed 12,000 hours accelerated aging test in China National Center for Test of Chemical Building Materials and the result is E≤5.



2 JL Roof Tile Loading Resistance

By test, in condition of 660 supporting span and 100kg applied load there is no crack or any damage in JL roof tile.



3 JL Roof Tile Installation

Quick and easy installation with large size of one single JL roof tile sheet.



4 Insulation

The coefficient of heat conductivity of JL roof tile is 0.325w/m, 1/3 of that of clay tile, 1/5 of that of cement tile and 1/2000 of that of 0.5mm thick color steel tile, thus owning good heat preservation.

Corrosion Resistance

Excellent anti-corrosion performance

The material of JL roof tile is resistant to many chemical materials. By test, there is no chemical action by dipping into concentrated hydrochloric acid, 90% acid, 60% nitric acid and 20% sodium hydroxide for 24 hours.



5 Water Proof

The material of JL roof tile is dense and 100% free of water absorption. The main JL roof tile is large in area and 30mm high in wave peak; the connection is tight, thus it is good in water tightness.



6 Impact Resistance and Low Temperature Resistance

According to the physical experiment, JL roof tile neither cracks when hitting by a 1kg steel ball free falling from 2m height nor breaks after 10 times of falling ball impact at a low temperature. Through 30 freeze thawing recycle testing of China National Center for Test of Chemical Building Materials, it is free of hollowness, frothing, peeling and crackle.



7 Light Weight

With the density of 6.1kg/m2, JL roof tile is able to effectively reduce the load of buildings, save the frame materials and facilitates moving and hoisting, then lowers construction cost.



8 Anti Flaming

The main material of JL roof tile is non- combustible polyvinyl chloride resin. JL roof tile is self-extinguishing and according to the test of China National Center for Test of Chemical Building Materials, it is fireproof performance reaches Class-B1.



9 Self-cleaning:

As the special design of the profile, the JL roof tile does not absorb dusts after being washed by rain.



10 Environment-friendly and Energy Saving

JL roof tile has passed the certification of “China Environmental Labeling Product". With the features of environmental protection, energy saving and recyclability, it has been energetically promoted by the country.



 Product Pictures







Roma type



Accessories:





Application













Certificate:
