3G Wcdma Real Time Gps Tracker Gps Tracking System With Acc

3G Wcdma Real Time Gps Tracker Gps Tracking System With Acc thumbnail-1
3G Wcdma Real Time Gps Tracker Gps Tracking System With Acc thumbnail-2
3G Wcdma Real Time Gps Tracker Gps Tracking System With Acc photo-1
3G Wcdma Real Time Gps Tracker Gps Tracking System With Acc photo-2
US$ 1 - 2 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Gps Tracker
Use:
Automotive
Screen Size:
Other
Contact Supplier Request Quote Chat Now
Megastek Technologies Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen HK door to door etc.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Gps Tracker
Use Automotive
Screen Size Other
Function Other
Place of Origin Guangdong, China
Brand Name Megastek
Model Number XT-007W
Warranty 12 Months

3G wcdma real time gps tracker gps tracking system with acc





Application:



  • Heavy motorbike
  • Intercity bus, school bus
  • Fleet management etc



Main Function:



  1. Water resistance (close to IP67)Compatible with built-in or external antennas
  2. Remove alarm
  3. Tracking via SMS/GPRS (TCP/UDP)
  4. Real time tracking
  5. Tracking regularly
  6. SOS emergency calling
  7. Geo-fence alarm
  8. Over speed alarm
  9. Internal battery low alarm
  10.  Car Low battery alarm
  11. Data logger (built-in 8M flash memory)
  12. Remotely monitoring
  13. Has 2 digital outputs, 3 digital inputs and 2 analog inputs
  14. ACC detection
  15. Oil detection
  16. Remote fuel/engine cut off
  17. Cut external power off alarm
  18. Hitting alarm
  19. 3G accelerometer





Specification:



Items Specification
Power Supply DC 9-33V/1.5A
Backup Battery Rechargeable 430 mAh battery (3.7V),
Normal Power Consumption 60mA
Dimension 88mm*50mm*20mm
Weight 87g
Operating Temperature Built in battery -25°C to +60°C standard(-40°Cw/optional battery)
Humidity 5% to 95% Non-condensing
GSM Module EUX XT-007E GSM/GPRS/EDGE900/1800MHZUMTS/HSDPA900/2100MHZ
NAX XT-007N GSM/GPRS/EDGE850/1900MHZUMTS/HSDPA850/1900MHZ Two types of modules, when using, must confirm local 2 g (GSM) and the frequency of 3 g (WCDMA)
GPS IC UBLOX GPS IC
GPS Sensitivity -161 dB
GPS Frequency L1, 1575.42 MHz
C/A Code 1.023 MHz
Channels 50 channel
Position Accuracy < 10 M 2D RMS
Velocity Accuracy 0.1 M/S
Time Accuracy 1 us synchronized to GPS time
Reacquisition 0.1 s (average)
Hot Start 3 sec., average
Cold(warm) Start 37sec., average
Altitude Limit 18,000 meters (60,000 feet) max.
Velocity Limit 500 meters/second (1000 knots) max.
Acceleration Limit Less than 4g
LED 3 LED lights to show power (red), GPS (yellow), GSM (blue).
Button SOS button, use for SOS emergency calling and sending SOS SMS.
Interface 2 digital outputs; 3 digital inputs; 2 analog inputs.















Accessories





PC platform and APP

PC platform and Mobile APP tracking and monitoring



Our Demo Platform: /gps

Login: Guest

Password: 666666























Company Profile





Certifications









Trade Shows



FAQ

1. Why SIM card in tracker does not support GPRS function?



A: Enable SIM card GPRS function.



2. Why  GPRS function of tracker is turned off ?



A: Turn on GPRS function of tracker.



3. Incorrect IP address or PORT



A: Get the right IP address and PORT and reset to tracker.



4. Why  GSM signal is weak?



A: Move the tracker to a location with good GSM reception.
