VDE CE Approval 250v 2.5a 10a 16a European ac Power Cord

Name: VDE CE Approval 250v 2.5a 10a 16a European ac Power Cord
Brand: donglan
SKU: 115565495
Availability: InStock

US$ 2.00 - 2.00 MOQ: 1000 Pieces

Key Specifications

Place of Origin:

Jiangxi, China

Brand Name:

donglan

Model Number:

audio

Jiangxi Donglan Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangxi, China

Brand Name donglan

Model Number audio

Type Other

Application Other

Conductor Material Copper

Conductor Type Stranded

Insulation Material PVC

VDE CE approval 250v 2.5a 10a 16a European ac power cord

Product Description

Professional Power Cords Parametric Test

Item	VDE CE approval 250v 2.5a 10a 16a European ac power cord
Applications:	Suitable for general household electrical appliances and office equipment
Environmental requirements	Working temperatures: 0~40°C, 20-90%RH
Environmental requirements	Storage temperatures: -20~80°C, 20-90%RH
Jacket:	Flame-retardant PVC
Insulation:	Color coded PVC or SR-PVC
Tests	UL VW-1 & CSA FTI vertical flame test Aging Test (Elogation and Strength test) DVW Test: 1500VAC, 1S Polarization and Contiunity Test Connector Rated Power Test
Wire type	H03VVH2-F 2X0.75mm² H05VVH2-F 2X0.75mm² H03VV-F 2X0.75mm² H05VV-F 2X0.75mm² H03VV-F 3G0.75-1.0-1.5mm² H05VV-F 3G0.75-1.0-1.5mm² H05RR-F 3G0.75-1.0-1.5mm² H05RN-F 3G0.75-1.0-1.5mm² H03RT-H 3G0.75-1.0-1.5mm²

Electrical performance standard

Voltage/frequency:	250V/50Hz
Plug rating:	10/13/16A 250V/125V
Conductor Type:	Annealed soft bare copper wire
Number of conductors:	3
Conductor size:	0.75mm2, 1mm2, 1.5mm2
Conductor construction:	24/0.2
Cord jacket diameter:	6.35±0.2
Temperature rating:	60℃- 300 ℃
RoHS compliance	Yes
