Help CenterHeat Resistant Insulation for Electrical Wire Household Appliances PVC Insulation Flexible Twisted Wire With Good Quality
Related Products
-
PVC Cable Twisted Pair Wire 300/500V Cu / CCA Electrical WireUS$ 2.00 - 2.00MOQ: 1000 Pieces -
450/750V PVC Twisted Electric Wire 2.5mm Square Rvs CableUS$ 2.00 - 2.00MOQ: 1000 Pieces
-
2.5 SQMM PVC Insulated Stranded Flexible Twisted Pair Electric WireUS$ 2.00 - 2.00MOQ: 1000 Pieces
-
Two Core Household Flexible Twisted Pair Electric WireUS$ 2.00 - 2.00MOQ: 1000 Pieces
-
Twined Audio Cable Twist Speaker Cable Wire Twist WireUS$ 2.00 - 2.00MOQ: 1000 Pieces
Specifications
1. Model No. RVB, RVVB,RVS heat resistant insulation for electrical wire
2. Voltage: 300/300V, 300/500V
3. Wires & Cables professional manufacturer
4. OEM acceptable
1. Application:
This product is fit A.C rated voltage up to and including 300/500V.
2. Use:
This product is suitable to be used in household appliances, electric tools and lighting.
3. Structure:
A: Copper Conductor
B: PVC Insulated
C: PVC Sheathed
4. Production Standards:
60227 IEC 42
60227 IEC 52
JB8734.3
5. Conductor:
Copper
6. Insulation:
PVC(Polyvinyl Chloride)
7. Jacket
PVC(Polyvinyl Chloride)
8. Operating Characteristics:
A. The permissible long-term operating temperature of cable conductor shall not exceed 70°C.
9. Specifications:
RVB 300/300V (60227 IEC 42) | |||
|
Nominal Section (mm2) |
Approximate O.D. (mm2) |
Conductor Resistance (20°C,Ω/km) |
Approximate Weight (kg/km) |
2x0.3 |
2.3X4.3 |
69.2 |
12.5 |
2x0.4 |
2.5X4.6 |
48.2 |
16.0 |
2x0.5 |
3.0X5.8 |
39.0 |
20.5 |
2x0.75 |
3.2X6.2 |
26.0 |
27.5 |
2X1.0 |
3.4X6.6 |
19.5 |
33.0 |
RVVB 300/500V (60227 IEC 52) | |||
2x0.75(A) |
7.6 |
26.0 |
50.2 |
2x0.75(B) |
5.0X7.6 |
26.0 |
35.0 |
2x1.0 |
7.8 |
19.5 |
69.9 |
2x1.5 |
8.8 |
13.3 |
92.0 |
2x2.5 |
11.0 |
7.98 |
132.8 |
3x0.75 |
8.0 |
26.0 |
66.1 |
3x1.0 |
8.4 |
19.5 |
83.3 |
3x1.5 |
9.6 |
13.3 |
114.7 |
3x2.5 |
11.5 |
7.98 |
160.9 |
4x0.75 |
8.6 |
26.0 |
81.1 |
4x1.0 |
9.2 |
19.5 |
102.4 |
4x1.5 |
11.0 |
13.3 |
147.3 |
4x2.5 |
12.5 |
7.98 |
203.5 |
5x0.75 |
9.4 |
26.0 |
98.7 |
5x1.0 |
11.0 |
19.5 |
125.0 |
5x1.5 |
12.0 |
13.3 |
178.6 |
5x2.5 |
14.0 |
7.98 |
246.7 |
RVS 300/300V (JB8734.3,Q/HY001) | |||
2x0.5 |
2.4X4.8 |
39.0 |
18 |
2x0.75 |
2.8X5.6 |
26.0 |
25 |
2x1.0 |
3.0X6.0 |
19.5 |
30 |
2x1.5 |
3.2X6.6 |
13.3 |
43 |
2x2.5 |
3.8X7.8 |
7.98 |
67 |
