Specifications
1)Aluminium alloy,solid and light2)Remote control
3)Both electric and manual operation
4)Anti-dropping device
5)ISO9001,CE
Automatic door motor FJJ412-3P(600)
Technical parameter:
| Model | Maximum weight doors(Kg) |
Maximum lift height (M) |
Power (W) |
Rated current(A) | Output torque(N.m) | Big wheel rolls turn(r/min) | Chain No. |
Carton Size (CM) |
Accessories Carton Size (CM) |
| 380V 50HZ (380V 60HZ) | |||||||||
| FJJ168-3P-(300) | 300 | 6.5 | 180 | 1.2 | 168 | 6.2 | 10A | 54*26*20.5 | 53*33*10 |
| FJJ343-3P-(500) | 500 | 6.5 | 250 | 1.3 | 343 | 6.2 | 10A | 54*26*20.5 | 53*33*10 |
| FJJ412-3P-(600) | 600 | 6.5 | 250 | 1.3 | 412 | 6.2 | 10A | 54*26*20.5 | 57.5*33*10 |
| FJJ607-3P-(800) | 800 | 7 | 300 | 2 | 607 | 3.4 | 10A | 55.5*26.5*26.5 | 68*37*12 |
| FJJ1102-3P-(1000) | 1000 | 8 | 400 | 2.3 | 1102 | 6.5 | 12A | 56*27*27 | 68*37*12 |
| FJJ1372-3P-(1300) | 1300 | 8 | 600 | 3 | 1372 | 6.5 | 12A | 56*27*27 | 68*37*12 |
| FJJ1610-3P-(1500) | 1500 | 8 | 600 | 3.2 | 1610 | 5.7 | 12A | 56*27*27 | 76*36*12 |
1) Shell: Aluminium alloy, solid and light but durable and easy to install.
2) Gear: High-quality alloy steel and special technical treatment to guarantee the strong hoist.
3) Brake structure: special device mechanical brakes, power cut off in an instant the brakes, to ensure absolute safety brake.
4) Limit System: Correct control, easy operation, and big control range.
5) Transmission System: High accuracy, smooth running, and low noise.
6) Anti-dropping device: Preventing accidental injury and ensure safety.
Notice: Your prompt inquiry after the Above Technical Parameters will be highly appreciated. Thanks!
ATTENTION: 1. THE POWER USED MUST BE ABOVED 380V.
2. THIS TYPE IS USED IN SPECIAL PLACE.
