Product Description:
Conductor: RG59: solid bare copper/copper clad steel
Power cable: stranded bare copper
Insulation: FPE/solid PE
Shield: Al foil
Braiding: Tinned copper/bare copper/copper clad aluminium/AL wire
Jacket: PVC
Technical characteristics:
conductor diameter: coaxial conductor: 1/20awg(solid)
power conductor:2/18awg(stranded)
Dielectric diameter: 3.66±0.5mm(coaxial)
1.5mm(power)
Outer cable diameter: 6mm(coaxial)
4mm(power)
Temperature range: -20°C~+75℃(-4°F~+167°F)
Outdoor installation: -5°C(23°F)
Minimum bend radius: 18.55mm(cabling)
61.50mm(repeated bending)
Pulling tension: 372.1 N
Crush resistance of cable: <1%
Product Application: Security system, CCTV, video conference, SATV
