Fine Sand Recycler With Direct Seller
US$ 9,500 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Fine Sand Recycle
Application:
mineral ore, slag,rocks,coal,coke,scoria and fire-proof matrials.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Ningbo Tianjin etc
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Factory Direct Sell Sand Collecting MachineUS$ 9,500 - 20,000MOQ: 1 Set -
Direct Sell Sand Recycle EquipmentUS$ 9,500 - 20,000MOQ: 1 Set
-
Coarse Powder Hammer Mill Grinding MillUS$ 20,000 - 30,000MOQ: 1 Set
-
Direct Sell Sand Recycle MachineUS$ 9,500 - 20,000MOQ: 1 Set
-
Factory Direct Sell Sand Recycling MachineUS$ 9,500 - 20,000MOQ: 1 Set
Condition
New
Type
Other, Fine Sand Recycle
Application
mineral ore, slag,rocks,coal,coke,scoria and fire-proof matrials.
Motor Type
AC Motor
Power(W)
15-37
Capacity(t/h)
50-300
Place of Origin
Henan, China
Brand Name
TF
Model Number
HX series
Dimension(L*W*H)
Depends on the model
Weight
Depends on the model
Certification
CE,ISO
Warranty
12 Months
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Fine Sand Recycler:1.Polyurethane screen, longer service life
2.Built-in polyurethane lining
3.80% reclaim rate
Fine Sand Recycler
Product Description
Introduction to Fine Sand Recycler
Fine sand recycling machine as a new environment-friendly equipment, has been gradually applied in hydropower aggregate processing systems, glass raw materials processing systems, artificial sand production line, CPP coarse slime recovery and environmental engineering (mud purification, etc).
Fine sand recycling machine can effectively solve the problem of sand recovery. Recovery is widely used in the purification of fine sand mud, sand and gravel aggregates recycling issues hydropower systems, glass raw materials processing systems, artificial sand production line and coarse slime recovery of materials such as fine particles.
Teachnical parameters of Fine Sand Recycler
Models |
Pump motor(kw) |
Swirler diameter |
vibrating screen motor(kw) |
Capacity(m3/h) |
HX22-30 |
15 |
300 |
2×3 |
50-120 |
HX22-50(I) |
18.5 |
500 |
2×4 |
100-150 |
HX22-50(II) |
22 |
250×2 |
2×4 |
120-230 |
HX22-60(I) |
30 |
600 |
2×5.5 |
200-280 |
HX30-60(II) |
37 |
300×2 |
2×5.5 |
250-300 |
Working principle of Fine Sand Recycler
1. Fine sand recycling machine structure: consists of electrical machine, slurry pump, hydro cyclone, ZKR line vibrating screen, purge tank and material returning bin, etc.
2. Working process of fine sand recycling machine : the sand and water mixture is sent to hydro cyclone. After centrifugal grading enrichment, the fine sand is sent to vibrating screen by sand sinking mouth. After dehydration by vibrating screen, the fine sand is efficiently separated from water and a few of fine sand and clay come through material returning bin then come back to purge tank. When liquid surface in the purge tank is high, the discharge hole can adjust the liquid surface. The weight concentration of recycling materials in line vibrating screen is 70%-85%. Adjusting fineness modulus can be realized by changing pump rotation speed, changing pulp consistency, adjusting overflow water and changing sand sinking mouth. By the process above, the fine sand recovery system can finish three functions, cleaning, dehydration and grading.
Feathers Of Fine Sand Recycler
1. Investment is only one sixth of the foreign import machines;
2. Moisture of final material remain to be below 0.5%;
3. Recycling rate is over 85%;
4. Takes less space, less power or labor consumption;
5. Final sand is clean and high grade.
