Specifications
Rotary Drum Dryer For Material1.Moisture of raw materail can be reduced
2.Simple maintenance
3.Lower cost
4.Energy-saving
Rotary Drum Dryer For Material
The Rotary Drum Dryer For Material is formed by rotary body, lifting blade, driving device, supporting device and sealing ring.
The Rotary Drum Dryer For Material is a kind of high-efficiency, energy-saving drying machine manufactured by our company after many years’ of study on the basis of successful experience of the similar products at home and abroad. Among a wide range of these drying machine, this series of dryer machine is one of our flagship product. We are on the leading side both in design and manufacture of roasting equipment. It is mainly used to dry the mineral materials, such as iron ore, quartz ore etc. Furthermore, China dryers have well adaptability and they are generally applied in drying granular and massive ore, and they can also roast the materials with comparative high humidity and the mineral waste residue.
Specification (model) |
Cylinder volume |
Cylinder speed |
Cylinder gradient |
Motor Model |
Motor Power |
Decelerator Model |
Overall dimensions |
Weight (T) |
FD600x8000 |
2.26 |
8 |
|
YCT200-4A |
4 |
JZQ250 |
8000x2200x980 |
2.9 |
FD800x1200 |
5.02 |
7 |
3-5 |
Y132M2-6 |
4 |
JZQ250 |
12000x2700x1300 |
3.5 |
FD1000×10000 |
7.85 |
6.73 |
3-5 |
Y132M2-6 |
4 |
JZQ400 |
10000×1876×2069 |
7.5 |
FD1200×6000 |
6.8 |
5.8 |
Y132M2-6 |
5.5 |
JZQ500 |
6000×2159×2475 |
7.97 |
|
FD1200×8000 |
9.1 |
Y132M2-6 |
5.5 |
JZQ500 |
8000×2159×2475 |
8.75 |
||
FD1200×10000 |
11.31 |
Y160M-6 |
7.5 |
JZQ500 |
10000×2159×2475 |
9.25 |
||
FD1200×12000 |
13.75 |
Y160M-6 |
7.5 |
JZQ500 |
12000×2159S×2475 |
10.3 |
||
FD1500×8000 |
14.14 |
4.8 |
Y160L-6 |
11 |
JZQ650 |
8000×2655×2859 |
14.74 |
|
FD1500×10000 |
|
Y160L-6 |
11 |
JZQ650 |
10000×2655×2895 |
15.9 |
||
FD1500×12000 |
21.2 |
Y180L-6 |
15 |
JZQ650 |
12000×2055×2895 |
17.13 |
||
FD1500×14000 |
24.9 |
Y180L-6 |
15 |
JZQ650 |
14000×2655×2895 |
18.33 |
- Material to be dried enters the dryer, and as the dryer rotates, the material is lifted up by a series of internal fins lining the inner wall of the dryer. When the material gets high enough to roll back off the fins, it falls back down to the bottom of the dryer, passing through the hot gas stream as it falls. Thus, the drying efficiency is much improved.
Personalized reception: Offer the full and personalized service in the whole journey after you come to China.
Lifetime Technical Support: Offer one year of free equipment warranty and lifetime technical support.
Monitor Production Progress: You can monitor production progress personally any time after confirming the order.
Product Delivery: We have developed a long and good relationship with many shipping agents, such as APL, MSK, CSCL, MSC, etc.
Installation and Training: Send technicians to the client site for guiding the installation and adjustment, and training operators to complete the inspection and acceptance together with you.
Tengfei has developed a long and good relationship with many shipping agents , such as APL,COSCO,OOCL,MSK,MSC,etc.
Six Reasons of Choosing Tengfei:
- International high quality certification product chain
- Manufactures, more reasonable price
- Solid technical support and after-sales service
- Uphold the principle of “Customer Supreme”( Balance payment after equipments run normally)
- One-stop service, customized exclusive project feasibility report
- Exports more than 50 countries and regions, good customers feedback
