Large Capacity With Competitive Price Powder Drying Machine
- Qingdao Tianjin Ningbo Shanghai etc.
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Rotary Drying Equipment | |
| Place of Origin | Henan, China | Brand Name | TengFei | |
| Model Number | FD1000x10000 | Voltage | 380v,50Hz or as request | |
| Power(W) | 4 kw | Dimension(L*W*H) | 10000 x 1876 x 2069 | |
| Weight | 7.5 t | Certification | ISO, CE | |
| Warranty | 12 Months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Large Capacity with Competitive Price Powder Drying Machine
- Dryer is widely used for drying the chalk slags, coal powder, slags, clay and other materials in the building materials, metallurgy, chemical industry, cement industry.
- Dryer Machine has a better adaptability and can dry various materials with a simple and reliable operation.
5 Features of Powder Drying Machine
- Large production capability, continuous operation
- Simple structure, convenient operation
- Low malfunction, low maintenance cost
- Wide scope of application, can be used to dry the granular materials
- Great operating flexibility
Specifications of Powder Drying Machine
Specification (model) | Cylinder volume (m³) | Cylinder speed (r/min) | Cylinder gradient (°C) | Motor Model | Motor Power (KW) | Decelerator Model | Overall dimensions (MM) | Weight (T) |
FD600x8000 | 2.26 | 8 |
| YCT200-4A | 4 | JZQ250 | 8000x2200x980 | 2.9 |
FD800x1200 | 5.02 | 7 | 3-5 | Y132M2-6 | 4 | JZQ250 | 12000x2700x1300 | 3.5 |
FD1000×10000 | 7.85 | 6.73 | 3-5 | Y132M2-6 | 4 | JZQ400 | 10000×1876×2069 | 7.5 |
FD1200×6000 | 6.8 | 5.8 | Y132M2-6 | 5.5 | JZQ500 | 6000×2159×2475 | 7.97 | |
FD1200×8000 | 9.1 | Y132M2-6 | 5.5 | JZQ500 | 8000×2159×2475 | 8.75 | ||
FD1200×10000 | 11.31 | Y160M-6 | 7.5 | JZQ500 | 10000×2159×2475 | 9.25 | ||
FD1200×12000 | 13.75 | Y160M-6 | 7.5 | JZQ500 | 12000×2159S×2475 | 10.3 | ||
FD1500×8000 | 14.14 | 4.8 | Y160L-6 | 11 | JZQ650 | 8000×2655×2859 | 14.74 | |
FD1500×10000 |
| Y160L-6 | 11 | JZQ650 | 10000×2655×2895 | 15.9 | ||
FD1500×12000 | 21.2 | Y180L-6 | 15 | JZQ650 | 12000×2055×2895 | 17.13 | ||
FD1500×14000 | 24.9 | Y180L-6 | 15 | JZQ650 | 14000×2655×2895 | 18.33 | ||
FD1800×10000 | 25.45 | 3-5 | 5 | Y180L-6 | 15 | JZQ650 | 10000×3060×2980 | 17.93 |
FD1800×12000 | 30.5 | Y200L-6 | 18.5 | JZQ650 | 12000×3060×2980 | 19.89 | ||
FD1800×14000 | 35.1 | Y200L-6 | 18.5 | JZQ650 | 14000×3060×2980 | 20.85 | ||
FD1800×18000 | 45.8 | Y200L-6 | 22 | JZQ650 | 18000×3060×2980 | 22.3 | ||
FD2200×12000 | 45.6 | 4.4 | Y200L-6 | 22 | JZQ750 | 12000×3620×3570 | 30.31 | |
FD2200×14000 | 53.2 | Y200L-6
| 22 | JZQ750 | 14000×3620×3570 | 32.23 | ||
FD2200×18000 | 68.4 | Y225M-6 | 30 | JZQ750 | 18000×3620×3570 | 34.15 | ||
FD2200×20000 | 70 | Y225M-6 | 30 | JZQ750 | 20000×3620×3570 | 36.07 | ||
FD2400×14000 | 63.3 | 3.85 | Y225M-6 | 30 | JZQ850 | 14000×3860×3760 | 39.9 |
