Specifications
Gypsum Dryer1. Low moisture content of final product
2. Easy maintenance
3. Large Capacity
4. Flexible operation
Gypsum Dryer With Low Moisture Content Of Final Product
1. Brief Introduction of Gypsum Dryer :
- Gypsum Dryer is designed for gypsum, because it's initial moisture content is higher than other material, the specific gravity is small, large changes in liquidity in the drying process.
- Therefore, Gypsum Dryer needs a reasonable structure, reasonable energy consumption, simple process to drying wet fly ash to make its moisture content meet the use requirements.
2. Technical Parameters of Gypsum Dryer
Specification (model) |
Cylinder volume (m³) |
Cylinder speed (r/min) |
Cylinder gradient (°C) |
Motor Model |
Motor Power (KW) |
Decelerator Model |
Overall dimensions (MM) |
Weight (T) |
FD600x8000 |
2.26 |
8 |
YCT200-4A |
4 |
JZQ250 |
8000x2200x980 |
2.9 |
|
FD800x1200 |
5.02 |
7 |
3-5 |
Y132M2-6 |
4 |
JZQ250 |
12000x2700x1300 |
3.5 |
FD1000×10000 |
7.85 |
6.73 |
3-5 |
Y132M2-6 |
4 |
JZQ400 |
10000×1876×2069 |
7.5 |
FD1200×6000 |
6.8 |
5.8 |
Y132M2-6 |
5.5 |
JZQ500 |
6000×2159×2475 |
7.97 |
|
FD1200×8000 |
9.1 |
Y132M2-6 |
5.5 |
JZQ500 |
8000×2159×2475 |
8.75 |
||
FD1200×10000 |
11.31 |
Y160M-6 |
7.5 |
JZQ500 |
10000×2159×2475 |
9.25 |
||
FD1200×12000 |
13.75 |
Y160M-6 |
7.5 |
JZQ500 |
12000×2159S×2475 |
10.3 |
||
FD1500×8000 |
14.14 |
4.8 |
Y160L-6 |
11 |
JZQ650 |
8000×2655×2859 |
14.74 |
|
FD1500×10000 |
Y160L-6 |
11 |
JZQ650 |
10000×2655×2895 |
15.9 |
|||
FD1500×12000 |
21.2 |
Y180L-6 |
15 |
JZQ650 |
12000×2055×2895 |
17.13 |
||
FD1500×14000 |
24.9 |
Y180L-6 |
15 |
JZQ650 |
14000×2655×2895 |
18.33 |
||
FD1800×10000 |
25.45 |
3-5 |
5 |
Y180L-6 |
15 |
JZQ650 |
10000×3060×2980 |
17.93 |
FD1800×12000 |
30.5 |
Y200L-6 |
18.5 |
JZQ650 |
12000×3060×2980 |
19.89 |
||
FD1800×14000 |
35.1 |
Y200L-6 |
18.5 |
JZQ650 |
14000×3060×2980 |
20.85 |
||
FD1800×18000 |
45.8 |
Y200L-6 |
22 |
JZQ650 |
18000×3060×2980 |
22.3 |
||
FD2200×12000 |
45.6 |
4.4 |
Y200L-6 |
22 |
JZQ750 |
12000×3620×3570 |
30.31 |
|
FD2200×14000 |
53.2 |
Y200L-6
|
22 |
JZQ750 |
14000×3620×3570 |
32.23 |
||
FD2200×18000 |
68.4 |
Y225M-6 |
30 |
JZQ750 |
18000×3620×3570 |
34.15 |
||
FD2200×20000 |
70 |
Y225M-6 |
30 |
JZQ750 |
20000×3620×3570 |
36.07 |
||
FD2400×14000 |
63.3 |
3.85 |
Y225M-6 |
30 |
JZQ850 |
14000×3860×3760 |
39.9 |
3. Features of Gypsum Dryer
- Gas low temperature, dust removal equipment with long time
- The new type of composite feed device, easily control to the end of the moisture indicator
- High degree of automation,transmission powder is small,easy operation,stable running
- Fuel can adapt to coal,oil and gas
4. Structure of Gypsum Dryer
- Heating system part uses the hot blast stove technology, sufficient heat and heat transfer effect is good,structure simple
- Heat exchange system is the drying cylinder, cylinder body feed plate staggered into spiral, repeatedly kick up materials, high heat efficiency
- Ventilation dust removal system is dust collecting equipment, after drying,the flyash under the nagative pressure condition, easy being taken away by the airflow, prevent the flyash be absort and discharged into the atmosphere by the induced draught system caused resource waste and environmental pollution,unified by the filter dust collector.
