China Vibrating Screen With High Capacity
- 28 Set / Sets per Month
- Qindao Tianjin ShangHai etc.
- T/T
Product Details
Condition: | New | Type: | Circular | Application: | Ore |
Place of Origin: | Henan, China | Brand Name: | TengFei | Model Number: | YZS Series |
Voltage: | Customized | Power(W): | 11-22kw | Dimension(L*W*H): | Different |
Weight: | 3.2-12.78t | Certification: | CE ISO | Warranty: | 12 Months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
China Vibrating Screen With High Capacity :1. Ring groove rivet connection
2. Advanced structure
3. Excellent durability
China Vibrating Ccreen
Henan Teng Fei Machine Manufacturing Co., Ltd. is a professional machine mining manufacturer with decades of years' experience. Our main product are grinding mills, Crushers,Dryer,Ball Mill, Sand making&washing machines, vibrating screens, etc. We manufacture TengFei brand mining machinery which are 100% of our own design, production detection and marketing.
Type: Necessary Equipmen
Max. Feed Size: 0-400mm
Handing Capacity:10-500t/h
Processed Materials: River Gravel, Granite, Basalt, Quartz, Iron ore, Diabase, Limestone, Coal Gangueetc.
Applications: Aggregate Field, Concrete Mixing Plant, Dry Motar Plant Desulfurization, Quartz Sand etc.
Working Principle
- Vibrating screen is manufactured for stand alone or supplemental installations.
- It can be manufactured in customized shape and size fit to the crusher and other processing applications and production requirements.
- Vibro screens are suitable with various screening systems. It can be installed and integrated with existing crusher units and plants.
- Screens are used for discharging bulky goods, sand, gravel, coal, mineral ores and coke from hoppers to crusher.
Technical Parameters
Model | Screen Size (mm) | No. of Layer | Screen mesh (mm) | Max. feed size (mm) | Handling capacity (t/h) | Motor power (Kw) | Vibrating frequency (r/min) |
2YZS1237 | 3700×1200 | 2 | 3-100 | 400 | 10-80 | 11 | 750-950 |
3YZS1237 | 3700×1200 | 3 | 3-100 | 400 | 10-80 | 11 | 750-950 |
2YZS1548 | 4800×1500 | 2 | 3-100 | 400 | 30-200 | 15 | 750-950 |
3YZS1548 | 4800×1500 | 3 | 3-100 | 400 | 30-200 | 15 | 750-950 |
2YZS1848 | 4800×1800 | 2 | 3-100 | 400 | 50-250 | 18.5 | 750-950 |
3YZS2160 | 6000×2100 | 3 | 3-100 | 400 | 81-720 | 30 | 700-900 |
4YZS2160 | 6000×2100 | 4 | 3-100 | 400 | 81-720 | 30 | 700-900 |
2YZS2460 | 6000×2400 | 2 | 3-150 | 400 | 100-500 | 30 | 700-900 |
How is the quality of your products?
- Our products are manufactured strictly according to national and international standard,and we take a test on every grinder before delivered out. If you want see our quality certifications and all kinds of testing report, please just ask us for it.
Guaranteed:
- If products’ quality don’t accord to description as we give or the promise before you place order,we promise 100% refund
How about price?
- Yes, we are factory and be able to give you lowest price below market one and we have a policy that “ for saving time and absolutely honest business attitude, we quote as lowest as possible for any customer, and discount can be given according to quantity”, if you like bargain and factory price is not low enough as you think, just don’t waste your time.Please trust the quotation we would give you, it is professional one.
