Help CenterWhite Pure Tungsten Flament for Sale
Related Products
-
White Pure Tungsten Wire for SaleUS$ 100 - 250MOQ: 1 Kilogram -
Polishing Lathed Thin Tungsten Bar for SaleUS$ 100 - 250MOQ: 1 Piece
-
High Purity Ground Pure Tungsten Plate Block Ingot for Sale for Coating FilmUS$ 100 - 250MOQ: 1 Piece
-
White Annealing Straight Pure Tungsten Wire for SaleUS$ 100 - 250MOQ: 1 Kilogram
-
Straight Tungsten WireUS$ 100 - 250MOQ: 1 Kilogram
Specifications
1.tungsten wire rod bar 99.95%purity,2.According to the drawing processing
3.good service
tungsten bar are extensively used in manufacturing industry and other industries
Manufacturing process of tungsten wire:
Tungsten wire
comes out through the process of heating, forging of tungsten rod, and then straightened for several times.
Tungsten wire applications:
Tungsten wire is universally used to make
tungsten wire resistance
for bulb, lamps. Besides, it can be used in making optical instrument, electric vacuum components, high temperature resistant parts.
Properties of tungsten wire:
Tungsten wire is characterized by highest melting point, excellent electric conductivity. It has high performance in sintering and high temperature in recrystallization. For the above features, it can serve a long life in any applications.
Tungsten wire dimensional tolerances lengths:
| dia(um) | min.length | ||||||
| weight(mg/200mm) | dia | ||||||
| class0 | classI | classII | classI | classII | |||
| 10<d<=18 | >0.30-0.98 | -- | ±3 | ±4 | -- | -- | |
| 18<d<=40 | >0.98-4.85 | ±2 | ±2.5 | ±3 | -- | -- | 400 |
| 40<d<=80 | >4.85-19.39 | ±1.5 | ±2.0 | ±2.5 | -- | -- | |
| 80<d<=150 | >19.39-68.18 | ±1.0 | ±1.5 | ±2.0 | -- | -- | 300 |
| 150<d<=300 | >68.18-272.71 | ±1.0 | ±1.5 | ±2.0 | -- | -- | 100 |
| 300<d<=350 | >272.71-371.19 | -- | ±1.0 | ±1.5 | -- | -- | 50 |
| 350<d<=500 | -- | ±1.5 | ±2.0 | * | |||
| 500<d<=1800 | -- | ±1.0 | ±1.5 | ||||
T/T . L/C....AND SO ON,
