Help CenterM58 5 Pin Panel Male and Female Connector for Led Light
Related Products
-
5 Pin Industrial Power PlugUS$ 12 - 13MOQ: 50 Pieces -
Waterproof Industry Plug ConnectorUS$ 12 - 13MOQ: 100 Pieces
-
High Current ConnectorUS$ 12 - 13MOQ: 50 Pieces
-
M58 IP67 Straight Male and Female Waterproof Wire ConnectorUS$ 12 - 13MOQ: 50 Pieces
-
M58 IP67 100A Straight Male and Female Waterproof Wire ConnectorUS$ 12 - 13MOQ: 50 Pieces
Specifications
Protected from dust and water during immersion,resistant to many oils and chemical.
Description |
Details |
Code |
1. Connector Size |
JKGL-M58 |
M58 |
2. Current Rating |
60-100A |
60-100 |
3. Number of Contacts |
2,3,4,5 |
2-5 |
4. Connector Type |
Without SR/SR |
B/S |
5. Connector Gender |
Male,Female |
M,F |
6. Contact Gender |
Male,Female |
M,F |
7. Assembly Style |
Field Installation /Molding(Solder) |
M |
8. Mating Style |
Screw |
S |
9. Backs hell |
Straight |
L |
10. Waterproof Rating |
IP67 |
7 |
|
Material: Core Material: PA6+30%GF UL94V0 Mold Material: Waterproof PVC Pin and Hole: Brass, Nickle Plated or Gold plated Sealing: Silicone Cable: Customize Other type cable for customize | ||
|
Property : Contact Resistance: <5mΩ Insulation Resistance: ≥500 MΩ at DC500V Breakdown Voltage: ≥2.5kV normal, 1.0kV water Temperature Rating: -45°C~+105°C Protection Ration: IP67, 300mm water half an hour Durability: 3K plug/Unplug Cycles
| ||
|
It is widely used in ·New energy ·LED ·Industrial control product ·Automotive ·Security product ·Power Supply ·Electric Vehicle ·Solar Energy ·IPC ·Various Mold It is high performance and competitive price. Welcome OEM/ODM.
| ||
Company profile:
INSTANTWARE is now manufacturing the whole range of ,M8,M12,M16,M23 7/8"waterproof connector and normalized Din 43650 rectangular connectors type A,B,C, both to be cabled and molded,with or without electrinic components.The connection products are widely sed in field bus components,Ethernet,solenoid valves,pressure sitches,motors-control,protoelectric barries,flow monitoring devices,proximity switches,and sensors in the hydraulic,pneumatic and automation industries.
Iastantware as a total-solution provider,also produces cable harness for automative diagnostic service,industrial connectivity,medical equipments,HVAC climate control technologies.The products have been world-widely exported to the markets as in:Germany,Sweden,Denmark,Australia,Dutchland,UK,Spain,Italy,Irael,USA,Canada and Asia.
Welcme to send us enquiry and we will give you prompt reply and make satisfaction based on your requirements,and OEM is also offered!
