Home > Industrial Equipment & Components > Refrigeration Equipment > Cold Room > GREATCOOL Cold Room Refrigeration Air Cooled Condenser
GREATCOOL Cold Room Refrigeration Air Cooled Condenser
US$ 5 - 5,000
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
GREATCOOL
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
GREATCOOL Air Conditioner Parts Air Conditioner Condenser CoilUS$ 5 - 5,000MOQ: 10 Pieces -
GREATCOOL Other Refrigeration & Heat Exchange Equipment Refrigeration Air Cooled CondenserUS$ 5 - 500MOQ: 100 Pieces
-
GREATCOOL Heat Exchanger Refrigerator Condenser Refrigerator Condenser CoilUS$ 5 - 100MOQ: 100 Pieces
-
GREATCOOL Refrigeration & Heat Exchange Parts Air Cooled CondenserUS$ 5 - 20MOQ: 100 Pieces
-
GREATCOOL Other Refrigeration & Heat Exchange Equipment Refrigerator CondenserUS$ 5 - 5,000MOQ: 10 Pieces
Condition
New
Place of Origin
Zhejiang, China
Brand Name
GREATCOOL
Model Number
fc50
Voltage
220v
After-sales Service Provided
No overseas service provided
Certification
RoHs
Specifications
Refrigeration Air Cooled Condenser can customerized by drawings with low price and good qualitySpecifications of Refrigeration Air Cooled Condenser
Product Description
| SPECIFICATION of SFN Condenser | ||||||||||||||
| No. | Drawing No. | Dimensions (mm) | Heat Exchange Area m2 | FAN (φmm) |
Cooling Capacity (Watt) |
Rated Input of Fan Motor Watt |
||||||||
| La | Lb | Lc | D | Df | Di | Dg | H | 3.5mm | 2.5mm | |||||
| 1 | SFN-1/4HPD-A | 320 | 290 | 260 | 100 | 210 | 3/8 | 3/8 | 270 | 1.6 | 2.2 | 200 | 774 | 33 |
| 2 | SFN-1/4HPD-B | 235 | 230 | 925 | 38 | |||||||||
| 3 | SFN-1/3HPD | 360 | 330 | 300 | 100 | 260 | 3/8 | 3/8 | 320 | 2.4 | 3.4 | 250 | 1235 | 70 |
| 4 | SFN-3/8HPD | 360 | 340 | 310 | 100 | 260 | 3/8 | 3/8 | 320 | 2.5 | 3.5 | 250 | 1333 | 70 |
| 5 | SFN-1/2HPD | 360 | 330 | 300 | 120 | 260 | 3/8 | 3/8 | 290 | 3.3 | 4.6 | 250 | 1570 | 70 |
| 6 | SFN-3/4HPD-A | 390 | 360 | 330 | 120 | 260 | 3/8 | 3/8 | 320 | 4.1 | 5.7 | 250 | 1779 | 70 |
| 7 | SFN-3/4HPD-B | 310 | 300 | 2406 | 120 | |||||||||
| 8 | SFN-1HPD-A | 390 | 360 | 330 | 145 | 260 | 3/8 | 3/8 | 320 | 5.4 | 7.6 | 250 | 2025 | 70 |
| 9 | SFN-1HPD-B | 310 | 300 | 2817 | 120 | |||||||||
| 10 | SFN-1HP-CD | 660 | 630 | 600 | 160 | 2-260 | 1/2 | 1/2 | 295 | 6.7 | 9.4 | 2-250 | 3117 | 2-70 |
| 11 | SFN-1.5HPD | 460 | 430 | 400 | 145 | 310 | 1/2 | 1/2 | 320 | 6.5 | 9.1 | 300 | 3214 | 120 |
| 12 | SFN-1.5HPD-CD | 660 | 630 | 600 | 160 | 2-260 | 5/8 | 1/2 | 295 | 9.0 | 12.6 | 2-250 | 3476 | 2-70 |
| 13 | SFN-2HPD | 440 | 410 | 380 | 165 | 310 | 5/8 | 1/2 | 360 | 9.1 | 12.7 | 300 | 3867 | 140 |
| 14 | SFN-3HPD | 660 | 630 | 600 | 200 | 420 | 3/4 | 5/8 | 520 | 22.8 | 31.9 | 400 | 7775 | 180 |
| 15 | SFN-4HPD | 660 | 630 | 600 | 220 | 420 | 3/4 | 5/8 | 520 | 27.3 | 38.2 | 400 | 9550 | 180 |
| 16 | SFN-5HPD | 1110 | 1080 | 1050 | 200 | 2-420 | 7/8 | 5/8 | 520 | 39.9 | 55.9 | 2-400 | 13975 | 2-180 |
| 17 | TSFN-1/3HP | 295 | 265 | 235 | 150 | 235 | 3/8 | 3/8 | 260 | 2.4 | 3.4 | 230 | 1285 | 38 |
| 18 | TSFN--1/2HP | 390 | 360 | 330 | 150 | 235 | 1/2 | 3/8 | 260 | 3.8 | 5.3 | 230 | 1510 | 38 |
| 19 | TSFN-3/4HP | 460 | 430 | 400 | 150 | 235 | 1/2 | 3/8 | 260 | 4.6 | 6.4 | 230 | 1835 | 38 |
| 20 | TSFN-1HP | 590 | 560 | 530 | 160 | 2-235 | 5/8 | 1/2 | 260 | 6.0 | 8.4 | 2-230 | 2791 | 2-38 |
| 21 | TSFN-1.5HP | 645 | 615 | 580 | 160 | 2-235 | 5/8 | 1/2 | 260 | 8.0 | 11.2 | 2-230 | 3235 | 2-38 |
| Condenser Capacity calculations are based on the following conditions: | ||||||||||||||
| TA/Inlet Air temperature | 35 | |||||||||||||
| TC/Condensing temperature | 50 | |||||||||||||
| Refrigerant | R404A | |||||||||||||
| TD=TC-TA | 15 | |||||||||||||
| TE/Evaporation temperature | -10 | |||||||||||||
Our Services
Packaging & Shipping
More details about the condenser for air conditioner,please feel free to contact with us.
skype:ita1992
