GREATCOOL Industrial Air Conditioners Condenser For Cold Room
USD $5 - $5,000
/ Piece
10 Pieces(Min.Order)
- 15 Piece / Pieces per Month
- SHANGHAI NINGBO
- T/T D/P D/A Credit Card
You May Like
-
Crossflow plate fin heat exchangers air cooled heat exchanger
-
High efficiency heat and energy recovery exhaust ventilation system
-
Portable air fresher cooler ventilators
-
Night free cooling air fresher cooler ventilators
-
Summber by-pass energy saving air fresher cooler ventilators
-
Plate heat exchanger recuperator air fresher cooler ventilators
Product Details
| Condition: | New | Type: | Evaporative Air Cooler | Place of Origin: | Zhejiang, China |
| Brand Name: | GREATCOOL | Model Number: | fc61 | Mounting: | Floor Standing |
| Certification: | Other, RoHS, RoHs | After-sales Service Provided: | No overseas service provided |
Product Description
Specifications
Condenser For Cold Room can customerized by drawings with low price and good qualitySpecifications of Condenser For Cold Room
Product Description
| SPECIFICATION of SFN Condenser | ||||||||||||||
| No. | Drawing No. | Dimensions (mm) | Heat Exchange Area m2 | FAN (φmm) | Cooling Capacity (Watt) | Rated Input of Fan Motor Watt | ||||||||
| La | Lb | Lc | D | Df | Di | Dg | H | 3.5mm | 2.5mm | |||||
| 1 | SFN-1/4HPD-A | 320 | 290 | 260 | 100 | 210 | 3/8 | 3/8 | 270 | 1.6 | 2.2 | 200 | 774 | 33 |
| 2 | SFN-1/4HPD-B | 235 | 230 | 925 | 38 | |||||||||
| 3 | SFN-1/3HPD | 360 | 330 | 300 | 100 | 260 | 3/8 | 3/8 | 320 | 2.4 | 3.4 | 250 | 1235 | 70 |
| 4 | SFN-3/8HPD | 360 | 340 | 310 | 100 | 260 | 3/8 | 3/8 | 320 | 2.5 | 3.5 | 250 | 1333 | 70 |
| 5 | SFN-1/2HPD | 360 | 330 | 300 | 120 | 260 | 3/8 | 3/8 | 290 | 3.3 | 4.6 | 250 | 1570 | 70 |
| 6 | SFN-3/4HPD-A | 390 | 360 | 330 | 120 | 260 | 3/8 | 3/8 | 320 | 4.1 | 5.7 | 250 | 1779 | 70 |
| 7 | SFN-3/4HPD-B | 310 | 300 | 2406 | 120 | |||||||||
| 8 | SFN-1HPD-A | 390 | 360 | 330 | 145 | 260 | 3/8 | 3/8 | 320 | 5.4 | 7.6 | 250 | 2025 | 70 |
| 9 | SFN-1HPD-B | 310 | 300 | 2817 | 120 | |||||||||
| 10 | SFN-1HP-CD | 660 | 630 | 600 | 160 | 2-260 | 1/2 | 1/2 | 295 | 6.7 | 9.4 | 2-250 | 3117 | 2-70 |
| 11 | SFN-1.5HPD | 460 | 430 | 400 | 145 | 310 | 1/2 | 1/2 | 320 | 6.5 | 9.1 | 300 | 3214 | 120 |
| 12 | SFN-1.5HPD-CD | 660 | 630 | 600 | 160 | 2-260 | 5/8 | 1/2 | 295 | 9.0 | 12.6 | 2-250 | 3476 | 2-70 |
| 13 | SFN-2HPD | 440 | 410 | 380 | 165 | 310 | 5/8 | 1/2 | 360 | 9.1 | 12.7 | 300 | 3867 | 140 |
| 14 | SFN-3HPD | 660 | 630 | 600 | 200 | 420 | 3/4 | 5/8 | 520 | 22.8 | 31.9 | 400 | 7775 | 180 |
| 15 | SFN-4HPD | 660 | 630 | 600 | 220 | 420 | 3/4 | 5/8 | 520 | 27.3 | 38.2 | 400 | 9550 | 180 |
| 16 | SFN-5HPD | 1110 | 1080 | 1050 | 200 | 2-420 | 7/8 | 5/8 | 520 | 39.9 | 55.9 | 2-400 | 13975 | 2-180 |
| 17 | TSFN-1/3HP | 295 | 265 | 235 | 150 | 235 | 3/8 | 3/8 | 260 | 2.4 | 3.4 | 230 | 1285 | 38 |
| 18 | TSFN--1/2HP | 390 | 360 | 330 | 150 | 235 | 1/2 | 3/8 | 260 | 3.8 | 5.3 | 230 | 1510 | 38 |
| 19 | TSFN-3/4HP | 460 | 430 | 400 | 150 | 235 | 1/2 | 3/8 | 260 | 4.6 | 6.4 | 230 | 1835 | 38 |
| 20 | TSFN-1HP | 590 | 560 | 530 | 160 | 2-235 | 5/8 | 1/2 | 260 | 6.0 | 8.4 | 2-230 | 2791 | 2-38 |
| 21 | TSFN-1.5HP | 645 | 615 | 580 | 160 | 2-235 | 5/8 | 1/2 | 260 | 8.0 | 11.2 | 2-230 | 3235 | 2-38 |
| Condenser Capacity calculations are based on the following conditions: | ||||||||||||||
| TA/Inlet Air temperature | 35 | |||||||||||||
| TC/Condensing temperature | 50 | |||||||||||||
| Refrigerant | R404A | |||||||||||||
| TD=TC-TA | 15 | |||||||||||||
| TE/Evaporation temperature | -10 | |||||||||||||
Our Services
Packaging & Shipping
More details,please feel free to contact with us.
skype:ita1992
Contact Us
- Hangzhou Greatcool Refrigeration Equipment Co., Ltd.
- Contact nameTony Luo
- Phone0086-571-89262368
- AddressNo.78,Jinjiadai,Dongxin area,Yunhe Town,Yuhang district,Hangzhou City,China Hangzhou,Zhejiang
