TH3A /TK3A Counteweight Hollow Guide Rail / Rails for Elevator
Elevator Hollow Guide Rail TK3A(TH3A).
1. Basic dimensions: 78mm*60mm*16.4mm 2mm
Notes: bottom width is 78mm, height is 60mm, top width is 16.4mm, wall thickness:2.75mm.The wall thickness is 2mm for TK3A,the other size of TK3A is same with TK5A.
2. Basic dimensions of its matched accessories
Fishplate: 200mm*78mm*60mm;
3. Material: all types of guide rails’ material is Q235
Item Grade |
Chemical Composition |
||||
C |
Mn |
Si |
S |
P |
|
Q235 |
0.14-0.22 |
0.35-0.65 |
0.12-0.30 |
≤0.05 |
≤0.045 |
Mechanical property |
|
||||
Yield Strength N/mm2 |
Tensile Strength N/mm2 |
Elongation |
|
||
≥235 |
400-450 |
≥24 |
|
||
Other types elevator guide rails:
Cold draw guide rail :
T45/A:45*45*5mm; T50/A 50*50*5mm
T70/A: 70mm*65mm*9mm
Machined guide rail:
T70-1/B : 70mm*65mm*9mm
T75/B orT75-3/B: 75mm*62mm*10mm
T78/B: 78mm*56mm*10mm
T82/B: 82.5mm*68.25mm*9mm
T82-3/B:82mm*62mm*15.88mm
T89/B or T89-1/B: 89mm*62mm*16mm
T90/B: 90mm*75mm*16mm
T114/B:114*89*16mm
T127-1/B: 127*89*16mm
T127-2/B: 127*89*16mm
Hollow guide rail:
TK5A,TH5A
TK5,TH5
TK3A,TH3A
Since 2006, our factory has developed from a factory that mainly provides machinery processing services to a specialized manufacturer of a series of guide rails for elevators. These elevator guide rails are usually used for vertical lifts & elevators to slide up and down safely and smoothly.
Our factory has passed ISO 9001 certificate. And our guide rails has passed type test in our industry.
In 2008, we started the foreign trade business. The daughter of Mr.Qian is in charge of the foreign trade business. We are able to listen carefully to the needs of customers and prepare the goods well and quickly. With high quality , and reasonable price, our products garner a good reputation both in domestic and overseas markets.
Please check the picture for detailed link.
.
