HVPF Automatic Vertical Press Filter
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
HEXING
Model Number:
HVPF
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DXL-01 Luggage WrapperNegotiableMOQ: 1 Set -
DNT Series Box Wrapping MachineNegotiableMOQ: 1 Set
-
DW1600F Series Composite Type Reel Wrap MachineNegotiableMOQ: 1 Set
-
DW700F Series Composite Type Reel Wrap MachineNegotiableMOQ: 1 Set
-
DY500-P Mini Reel Stretch Wrapping MachineUS$ 8,000 - 9,000MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
HEXING
Model Number
HVPF
After-sales Service Provided
Engineers available to service machinery overseas
Press filter is a solid-liquid separation equipment with high-efficiency, energy-saving and high automation degree. This equipment adopts the hydraulic system, pump pressure, material gravity and air pressure or water pressure to form the differential pressure on both sides of the cloth, so it can achieve the high efficiency solid-liquid separation with lowest moisture of cake.
- The layered structure of filter plate adopts guide device to make sure the smoothly running
- It can continuously automatically finish the operation in the process og filtering, extrusion, washing, drying, discharging and filter cloth regeneration.
- The filter pressure can reach 1.6 Mpa. Especially have good effect on various sticky tiny materials and low moisture of filter cake.
- Hydraulic pressure is adopted in the drive device; keep the equipment safety in operation.
- Adopts PLC+touch screen + automatic valves to control, with the characteristics of flexible and simple operation, reduce the production cost and working strength
- Compact structure. Covers small area, large pressure and high working efficiency
1.High pressure water station 2.Control system 3.Slurry holding hopper 4.Below platen 5.Filter plate group
6.Upper platen 7.Side plate 8.Guidepost 9.Fliter cloth 10.Tension device 11.Correcting device
12.Drive device 13.Air-dry system 14.Hydraulic system 15.Washing device 16Top tight cylinder
17.Feeding pipe 18.Fast oil cylinder 19.Rack
